TP-Link TL-SG1008P özellikleri ve fiyatları

TP-Link TL-SG1008P teknik özellikleri

Model kodu

TL-SG1008P

Anahtar türü

Unmanaged

Ethernet bağlantıları

• 8× 10/100/1000 Mbps RJ45 Ports• AUTO Negotiation• AUTO MDI/MDIX

Desteklenen ağ kabloları

• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)• EIA/TIA-568 100Ω STP (maximum 100m)• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)• EIA/TIA-568 100Ω STP (maximum 100m)• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)• EIA/TIA-568 100Ω STP (maximum 100m)

İletim yöntemi

Store-And-Forward

Jumbo çerçeve

16 KB

Güç kaynağı

External Power Adapter(Output: 53.5VDC / 1.31A)

Güç tüketimi koşulları

• 4.7 W (220/50 Hz no PD connected)• 74.39 W (220/50 Hz with 64 W PD connected)

En yüksek ısı yayılımı

• 16.03 BTU/h (no PD connected)• 253.67 BTU/h (with 64 W PD connected)

Boyutlar

6.7×3.9×1.1 in (171×98×27 mm)

Soğutma fanları

Fanless

Sertifikalar

CE, FCC

Kutu içeriği

• TL-SG1008P• Power Adapter• Installation Guide

Ek anahtarlama özellikleri

• Compatible With IEEE 802.3af/at Compliant PDs• IGMP Snooping• Mac Address Auto-Learning And Auto-Aging• IEEE802.3x Flow Control• 802.1p/DSCP QoS• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)• PoE Auto Recovery (Ports 1-4)

Fiziksel güvenlik

Yes

RJ45 bağlantıları

8 port

Fansız tasarım

Var

Paket iletme hızı

11.904 Mpps

PoE güç koşulları

• Standard: 802.3 af/at compliant• PoE Ports: Ports 1–4• Power Supply: 64 W

PoE desteği

Var

Anahtarlama kapasitesi

16 Gbps

Çalışma sıcaklığı

0–40 ℃ (32–104 ℉);•

Saklama sıcaklığı

-40–70 ℃ (-40–158 ℉)•

Çalışma nemi

10–90% RH non-condensing•

Depolama nemi

5–90% RH non-condensing

Üreticinin ayrıntılı teknik bilgileri

Interface: • 8× 10/100/1000 Mbps RJ45 Ports• AUTO Negotiation• AUTO MDI/MDIX, Network Media: • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)• EIA/TIA-568 100Ω STP (maximum 100m)• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)• EIA/TIA-568 100Ω STP (maximum 100m)• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)• EIA/TIA-568 100Ω STP (maximum 100m), Fan Quantity: Fanless, Physical Security Lock: Yes, External Power Supply: External Power Adapter(Output: 53.5VDC / 1.31A), Packet Forwarding Rate: 11.904 Mpps, PoE Ports (RJ45): • Standard: 802.3 af/at compliant• PoE Ports: Ports 1–4• Power Supply: 64 W, Mac Address Table: 4K, Jumbo Frame: 16 KB, Switching Capacity: 16 Gbps, Dimensions ( W x D x H ): 6.7×3.9×1.1 in (171×98×27 mm), Max. Power Consumption: • 4.7 W (220/50 Hz no PD connected)• 74.39 W (220/50 Hz with 64 W PD connected), Max Heat Dissipation: • 16.03 BTU/h (no PD connected)• 253.67 BTU/h (with 64 W PD connected), Advanced Features: • Compatible With IEEE 802.3af/at Compliant PDs• IGMP Snooping• Mac Address Auto-Learning And Auto-Aging• IEEE802.3x Flow Control• 802.1p/DSCP QoS• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)• PoE Auto Recovery (Ports 1-4), Transmission Method: Store-And-Forward, Certification: CE, FCC, Package Content: • TL-SG1008P• Power Adapter• Installation Guide, Environment: • Operating Temperature: 0–40 ℃ (32–104 ℉);• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing
