InWin Diéy özellikleri ve fiyatları

InWin Diéy teknik özellikleri

Model kodu

Diéy

case Form Factor

Full Tower

motherboard Support

12" x 13" E-ATX, ATX, Micro-ATX

Boyutlar

800 x 960 x 960mm - 800 x 1300 x 1300mm 31.5" x 37.8" x 37.8" - 31.5" x 51.2" x 51.2" (The product dimensions vary depending on wing placement.)

panel Materials

Specifications / Materials: Aluminium, SECC, Plexiglass

drive Bays

Specifications / Internal Drive Bays: 4 x 3.5" / 2.5"

psu Support

Specifications / Power Supply Compatibility: ATX12V and EPS12V

fan Mounts

Specifications / Thermal Solution Compatibility: 1 x 120mm Left Side Fan / 120mm Radiator 3 x 120mm Right Side Fan / 360mm Radiator Side: 50mm Maximum Height including Fans (Radiators with unique designs may prevent installation)

clearance Conditions

Specifications / Maximum Compatibility: Graphics Card Length: 360mm Maximum (GPUs with unique designs may prevent installation) CPU Heatsink Height: 170mm (CPU Die Surface to Side Panel)

cpu Cooler Max Height Mm

170

part Number

IW-CS-DIEY

case Features

Specifications / Model Number: IW-CS-DIEY, Specifications / Colors: Water Blue

Üreticinin ayrıntılı teknik bilgileri

Specifications / Model: Diéy; Specifications / Model Number: IW-CS-DIEY; Specifications / Colors: Water Blue; Specifications / Case Type: Full Tower; Specifications / Materials: Aluminium, SECC, Plexiglass; Specifications / M/B Compatibility: 12" x 13" E-ATX, ATX, Micro-ATX; Specifications / Expansion Slots: PCI-E x 8; Specifications / Maximum Compatibility: Graphics Card Length: 360mm Maximum (GPUs with unique designs may prevent installation) CPU Heatsink Height: 170mm (CPU Die Surface to Side Panel); Specifications / Internal Drive Bays: 4 x 3.5" / 2.5"; Specifications / Thermal Solution Compatibility: 1 x 120mm Left Side Fan / 120mm Radiator 3 x 120mm Right Side Fan / 360mm Radiator Side: 50mm Maximum Height including Fans (Radiators with unique designs may prevent installation); Specifications / Power Supply Compatibility: ATX12V and EPS12V; Specifications / Product Dimensions (H x W x D): 800 x 960 x 960mm - 800 x 1300 x 1300mm 31.5" x 37.8" x 37.8" - 31.5" x 51.2" x 51.2" (The product dimensions vary depending on wing placement.); Specifications / Product Dimensions (H x W x D) with Hanging Bracket: 2300 x 1000 x 1500mm 90.6" x 39.4" x 59.1"; Specifications / Package Dimensions (H x W x D): 1190 x 1000 x 1000mm 46.9" x 39.4" x 39.4"
