InWin W50 özellikleri ve fiyatları

InWin W50 teknik özellikleri

Model kodu

W50

case Form Factor

Mid Tower

motherboard Support

12" x 10.9" E-ATX ( 305 x 277 mm ), ATX, Micro-ATX, Mini-ITX

Boyutlar

522 x 278 x 502 mm 20.5 x 10.9 x 19.7"

device Depth

522

En

278 mm

Boy

502 mm

panel Materials

Specifications / Materials: SPCC, Tempered Glass

front Io

Specifications / I/O Ports: 1 x USB 3.2 Gen 2x2 Type-C (20 Gbps) 2 x USB 3.2 Gen 1 HD Audio (CTIA - SPK/MIC) LED Lighting Control Switch Power Button

drive Bays

Specifications / Internal Drive Bays: 2 x 3.5" & 2 x 2.5"

psu Support

Specifications / Power Supply Compatibility: PSII: ATX12V - Length up to 238 mm

fan Mounts

Top: 3 x 120 / 2 x 140 mm Rear: 1 x 120 mm (VX120 pre-installed) Bottom: 2 x 120 mm ( screws required≧ 25mm ) Side: 3 x 120 mm (VX120 pre-installed) Water Cooling Radiators: Top: 1 x 240/ 280 / 360 mm Rear: 1 x 120 mm Side: 1 x 240 / 360 mm

clearance Conditions

Specifications / Maximum Compatibility: GPU Length: 435 mm CPU Heatsink Height: 175 mm

cpu Cooler Max Height Mm

175

gpu Max Length Mm

435

Ağırlık

11150 g

part Number

IW-CS-W50BLK-4VX120

case Features

Specifications / Model Number: IW-CS-W50BLK-4VX120

Üreticinin ayrıntılı teknik bilgileri

Specifications / Model: W50; Specifications / Model Number: IW-CS-W50BLK-4VX120; Specifications / Color: Black; Specifications / Case Type: Mid Tower; Specifications / Materials: SPCC, Tempered Glass; Specifications / M/B Compatibility: 12" x 10.9" E-ATX ( 305 x 277 mm ), ATX, Micro-ATX, Mini-ITX; Specifications / Expansion Slots: 8 x PCIe; Specifications / Maximum Compatibility: GPU Length: 435 mm CPU Heatsink Height: 175 mm; Specifications / I/O Ports: 1 x USB 3.2 Gen 2x2 Type-C (20 Gbps) 2 x USB 3.2 Gen 1 HD Audio (CTIA - SPK/MIC) LED Lighting Control Switch Power Button; Specifications / Internal Drive Bays: 2 x 3.5" & 2 x 2.5"; Specifications / Thermal Solution Compatibility: Air Cooling Fans: Top: 3 x 120 / 2 x 140 mm Rear: 1 x 120 mm (VX120 pre-installed) Bottom: 2 x 120 mm ( screws required≧ 25mm ) Side: 3 x 120 mm (VX120 pre-installed) Water Cooling Radiators: Top: 1 x 240/ 280 / 360 mm Rear: 1 x 120 mm Side: 1 x 240 / 360 mm; Specifications / Power Supply Compatibility: PSII: ATX12V - Length up to 238 mm; Specifications / Product Dimensions (L x W x H): 522 x 278 x 502 mm 20.5 x 10.9 x 19.7"; Specifications / Package Dimensions (L x W x H): 563 x 365 x 631 mm 22.1 x 14.3 x 24.8"; Specifications / Net Weight: 11.15 kg /24.58 lbs; Specifications / Gross Weight: 13.3 Kg /29.32 lbs
