Phanteks Eclipse G500A özellikleri ve fiyatları

Phanteks Eclipse G500A teknik özellikleri

Model kodu

PH-EC500GA_DBK01A

part Number

PH-EC500GA_DBK01A

case Form Factor

Mid-Tower

motherboard Support

General / Mainboard Support: E-ATX | ATX | Micro-ATX | Mini-ITX

Boyutlar

240 mm x 500 mm x 515 mm | 9.45 in x 19.69 in x 20.28 in

panel Materials

Steel chassis | Tempered glass

front Io

1x USB-C 3.2 Gen 2 2x USB 3.0 Microphone | Headphone D-RGB Mode Button D-RGB Color Button Power Button

Garanti

5 Years limited Learn more

vertical Gpu Support

3-slots Riser Cable sold separately

expansion Slots

7

drive Bays

General / Internal 2.5″ Bay: 9 + 10x 3.5″ HDD | General / Internal 3.5″ Bay: 10 | 2 Included + 9x 2.5″ SSD

fan Mounts

Fans 120 | 140 / Total Fans: 7x | 7x | Fans 120 | 140 / Top: 3x | 3x | Fans 120 | 140 / Front: 3x | 3x (pre-installed) | Fans 120 | 140 / Side: – | – | Fans 120 | 140 / Rear: 1x | 1x | Fans 120 | 140 / Bottom: – | –

radiator Support

Radiators 120 | 140 / Top: Max. 360 | 280 | Radiators 120 | 140 / Front: Max. 360 | 420 | Radiators 120 | 140 / Side: – | – | Radiators 120 | 140 / Rear: 120 | – | Radiators 120 | 140 / Bottom: – | –

clearance Conditions

Clearance / CPU Cooler Height: 185 mm | 7.28 in | Clearance / GPU Length: 435 mm | 17.12 in | Clearance / GPU Height: – | Clearance / Power Supply Length: 195 mm | 7.67 in | Clearance / Top Radiator Length x Width: ? x 70 mm | ? x 2.75 in | Clearance / Front Radiator Length x Width: 142 x 475 mm | 5.59 x 18.70 in | Clearance / Side Radiator Length x Width: – | Clearance / Bottom Radiator Length x Width: –

gpu Max Length Mm

435

cpu Cooler Max Height Mm

185

psu Max Length Mm

195

Ağırlık

10530 g

Kutu içeriği

Extra / Scope of Delivery: 1x Eclipse G500A chassis 3x SSD bracket 2x HDD bracket 3x M25-140 D-RGB fan, Extra / Accessory Box: 6x Zip ties 1x GPU anti-sag bracket 1x Vertical GPU mount, Extra / Screws: 22x Mainboard | SSD screws 7x Power supply screws 8x HDD locking screws 12x Thumb screws 8x Fan screws 8x Case screws 1x Motherboard stand-off 3x Riser cable screws 1x Stand-off removal tool

included Fans

1x Eclipse G500A chassis 3x SSD bracket 2x HDD bracket 3x M25-140 D-RGB fan

case Features

General / Side Window: Yes, General / Vertical GPU Support: 3-slots Riser Cable sold separately

Üreticinin ayrıntılı teknik bilgileri

General / Model No.: PH-EC500GA_DBK01A; General / UPC Code: 886523302612; General / Case Dimensions: 240 mm x 500 mm x 515 mm | 9.45 in x 19.69 in x 20.28 in; General / Form Factor: Mid-Tower; General / Mainboard Support: E-ATX | ATX | Micro-ATX | Mini-ITX; General / Materials: Steel chassis | Tempered glass; General / Side Window: Yes; General / PCI Slots: 7; General / Vertical GPU Support: 3-slots Riser Cable sold separately; General / Internal 2.5″ Bay: 9 + 10x 3.5″ HDD; General / Internal 3.5″ Bay: 10 | 2 Included + 9x 2.5″ SSD; General / Front I/O: 1x USB-C 3.2 Gen 2 2x USB 3.0 Microphone | Headphone D-RGB Mode Button D-RGB Color Button Power Button; Fans 120 | 140 / Total Fans: 7x | 7x; Fans 120 | 140 / Top: 3x | 3x; Fans 120 | 140 / Front: 3x | 3x (pre-installed); Fans 120 | 140 / Side: – | –; Fans 120 | 140 / Rear: 1x | 1x; Fans 120 | 140 / Bottom: – | –; Radiators 120 | 140 / Top: Max. 360 | 280; Radiators 120 | 140 / Front: Max. 360 | 420; Radiators 120 | 140 / Side: – | –; Radiators 120 | 140 / Rear: 120 | –; Radiators 120 | 140 / Bottom: – | –; Clearance / CPU Cooler Height: 185 mm | 7.28 in; Clearance / GPU Length: 435 mm | 17.12 in; Clearance / GPU Height: –; Clearance / Power Supply Length: 195 mm | 7.67 in; Clearance / Top Radiator Length x Width: ? x 70 mm | ? x 2.75 in; Clearance / Front Radiator Length x Width: 142 x 475 mm | 5.59 x 18.70 in; Clearance / Side Radiator Length x Width: –, Clearance / Bottom Radiator Length x Width: –; Extra / Net Weight: 10.53 kg | 23.21 lbs; Extra / Gross Weight: 12.70 kg | 27.99 lbs; Extra / Warranty: 5 Years limited Learn more; Extra / Scope of Delivery: 1x Eclipse G500A chassis 3x SSD bracket 2x HDD bracket 3x M25-140 D-RGB fan; Extra / Accessory Box: 6x Zip ties 1x GPU anti-sag bracket 1x Vertical GPU mount; Extra / Screws: 22x Mainboard | SSD screws 7x Power supply screws 8x HDD locking screws 12x Thumb screws 8x Fan screws 8x Case screws 1x Motherboard stand-off 3x Riser cable screws 1x Stand-off removal tool
