Phanteks Evolv X2 özellikleri ve fiyatları

Phanteks Evolv X2 teknik özellikleri

Model kodu

PH-ES524XTG_DBK01

part Number

PH-ES524XTG_DBK01

case Form Factor

Mid-Tower

motherboard Support

General / Mainboard Support: *E-ATX | ATX | Micro-ATX | Mini-ITX *Up to 280 mm wide | General / Rear ATX Mainboard Support: MSI Project Zero | ASUS BTF | Gigabyte Project Stealth

Boyutlar

454 x 228 x 588 mm | 17.87 x 8.98 x 23.15 in

panel Materials

Steel chassis | Aluminium panels | Tempered glass window | ABS plastic

front Io

2x USB 3.0 1x USB-C 3.2 Gen2x2 1x Microphone | Headphone combo Power button Reset button

Garanti

5 Years limited Learn more

vertical Gpu Support

Yes Riser cable sold separately

fan Mounts

Fans 120 | 140 / Total Fans: 7 | – | Fans 120 | 140 / Top: 3 | – | Fans 120 | 140 / Front: – | – | Fans 120 | 140 / Side: – | – | Fans 120 | 140 / Rear: 1 | – | Fans 120 | 140 / Bottom: 3 | –

clearance Conditions

Clearance / CPU Cooler Height: 170 mm | 6.69 in | Clearance / GPU Length: 380 mm | 14.96 in | Clearance / GPU Width: 170 mm | 6.69 in | Clearance / Power Supply: 250 mm | 9.84 in | Clearance / Top 360 Radiator Length x Width x Height: 415 x 130 x 32 mm | 16.34 x 5.12 x 1.25 in

gpu Max Length Mm

380

cpu Cooler Max Height Mm

170

Ağırlık

14200 g

Kutu içeriği

Extra / Scope of Delivery: 1x Evolv X2 chassis 1x Storage bracket Pre-installed 1x SSD bracket Pre-installed, Extra / Accessory Box: 30x Mainboard | SSD screws 4x Power supply screws 8x HDD screws 4x Vertical-GPU bracket screws 1x Mainboard stand-off, Extra / Screws: 6x Zip ties 1x Stand-off removal tool 1x D-RGB mainboard adapter 500 mm 1x Microfiber cloth

case Features

General / Rear ATX Mainboard Support: MSI Project Zero | ASUS BTF | Gigabyte Project Stealth, General / Vertical GPU Support: Yes Riser cable sold separately

Üreticinin ayrıntılı teknik bilgileri

General / Model No.: PH-ES524XTG_DBK01; General / UPC Code: 886523303688; General / Case Dimensions: 454 x 228 x 588 mm | 17.87 x 8.98 x 23.15 in; General / From Factor: Mid-Tower; General / Mainboard Support: *E-ATX | ATX | Micro-ATX | Mini-ITX *Up to 280 mm wide; General / Rear ATX Mainboard Support: MSI Project Zero | ASUS BTF | Gigabyte Project Stealth; General / Materials: Steel chassis | Aluminium panels | Tempered glass window | ABS plastic; General / Color: Brushed black aluminium; General / Expansion Slots: 8; General / Vertical GPU Support: Yes Riser cable sold separately; General / Internal 2.5″ Positions: 5 + 1x 3.5″ HDD; General / Internal 3.5″ Positions: 2 + 3x 2.5″ SSD; General / Front I/O: 2x USB 3.0 1x USB-C 3.2 Gen2x2 1x Microphone | Headphone combo Power button Reset button; Fans 120 | 140 / Total Fans: 7 | –; Fans 120 | 140 / Top: 3 | –; Fans 120 | 140 / Front: – | –; Fans 120 | 140 / Side: – | –; Fans 120 | 140 / Rear: 1 | –; Fans 120 | 140 / Bottom: 3 | –; Radiator 120 | 140 / Top: Max. 360 | –; Radiator 120 | 140 / Front: – | –; Radiator 120 | 140 / Rear: – | –; Radiator 120 | 140 / Bottom: – | –; Clearance / CPU Cooler Height: 170 mm | 6.69 in; Clearance / GPU Length: 380 mm | 14.96 in; Clearance / GPU Width: 170 mm | 6.69 in; Clearance / Power Supply: 250 mm | 9.84 in; Clearance / Top 360 Radiator Length x Width x Height: 415 x 130 x 32 mm | 16.34 x 5.12 x 1.25 in, Extra / Net Weight: 14.2 kg | 31.3 lbs; Extra / Gross Weight: 16.5 kg | 36.4 lbs; Extra / Warranty: 5 Years limited Learn more; Extra / Scope of Delivery: 1x Evolv X2 chassis 1x Storage bracket Pre-installed 1x SSD bracket Pre-installed; Extra / Accessory Box: 30x Mainboard | SSD screws 4x Power supply screws 8x HDD screws 4x Vertical-GPU bracket screws 1x Mainboard stand-off; Extra / Screws: 6x Zip ties 1x Stand-off removal tool 1x D-RGB mainboard adapter 500 mm 1x Microfiber cloth

Güncel mağaza teklifleri

Son 48 saat içinde doğrulanmış, stokta mağaza teklifi yok. Eski fiyatlar güncel teklif olarak gösterilmez.
