SAPPHIRE PULSE RX 560 4G G5 14 CU 11267-18 özellikleri ve fiyatları

SAPPHIRE PULSE RX 560 4G G5 14 CU 11267-18 teknik özellikleri

Model kodu

11267-18

part Number

11267-18

Grafik işlemci

RX 560, 14 nm FinFET 4th Graphics Core Next (GCN)

Grafik belleği (VRAM)

4 GB

Grafik belleği türü

GDDR5

Ekran kartı arayüzü

PCI-Express 3.0

GPU saat hızı ve çalışma koşulları

Up to 1226 MHz, Boost

Akış işlemcisi sayısı

896

Görüntü çıkışları ve kullanım koşulları

1x DVI-D 1x HDMI 1x DisplayPort 1.4

En yüksek görüntü çözünürlüğü

DisplayPort: 5120×2880@60Hz HDMI: 4096×2160@60Hz DVI:2560x1600@60Hz

bios Mode

UEFI

Soğutma sistemi

Single fan

Boyutlar

2 Slot, ATX Dimension: 210(L)X111.5(W)X36(H)mm

Kapladığı yuva genişliği

2 slot

Kart uzunluğu

210 mm

power Consumption Conditions

<90W

Güç bağlantıları

1 x 6-pin Power Connector PCI Express® 2

HDMI bağlantı sayısı

1 adet

DisplayPort bağlantı sayısı

1 adet

DirectX desteği

DirectX® 12

OpenGL sürümü

OpenGL® 4.5

Diğer ekran kartı özellikleri

Sapphire Features: Intelligent Fan Control III Long Life Capacitor Fuse protection, AMD Features: Radeon™ VR Ready Premium Radeon™ Software Radeon™ FreeSync Technology AMD LiquidVR™ Technology 4th Gen GCN Architecture Radeon™ Chill Radeon™ ReLive DirectX® 12 Technology AMD Eyefinity Technology (Gaming) AMD App Acceleration AMD CrossFire™ Technology AMD CrossFire™ (Bridgeless) 3rd Gen 14nm Process Technology OpenCL 2.0 OpenGL 4.5 AMD PowerTune Technology TrueAudio Next Unified Video Decoder (UVD) Video Code Engine (VCE) Virtual Super Resolution The Vulkan® API

Üreticinin ayrıntılı teknik bilgileri

GPU: RX 560, 14 nm FinFET 4th Graphics Core Next (GCN), Engine Clock: Up to 1226 MHz, Boost, Stream Processors: 896, Memory Size/Bus: 4GB GDDR5/128-bit, Memory Clock: 6000 MHz effective, Displays: Maximum 3 Outputs, Interface: PCI-Express 3.0, Resolution: DisplayPort: 5120×2880@60Hz HDMI: 4096×2160@60Hz DVI:2560x1600@60Hz, Output: 1x DVI-D 1x HDMI 1x DisplayPort 1.4, BIOS Support: UEFI, API: OpenGL® 4.5 OpenCL 2.0 DirectX® 12 Shader Model 5.0, Game Index: eSport, Sapphire Features: Intelligent Fan Control III Long Life Capacitor Fuse protection, AMD Features: Radeon™ VR Ready Premium Radeon™ Software Radeon™ FreeSync Technology AMD LiquidVR™ Technology 4th Gen GCN Architecture Radeon™ Chill Radeon™ ReLive DirectX® 12 Technology AMD Eyefinity Technology (Gaming) AMD App Acceleration AMD CrossFire™ Technology AMD CrossFire™ (Bridgeless) 3rd Gen 14nm Process Technology OpenCL 2.0 OpenGL 4.5 AMD PowerTune Technology TrueAudio Next Unified Video Decoder (UVD) Video Code Engine (VCE) Virtual Super Resolution The Vulkan® API, Cooler Type: Single fan, Form Factor: 2 Slot, ATX Dimension: 210(L)X111.5(W)X36(H)mm, Power Consumption: <90W, OS: Windows® 11, 10, Windows® 7, 64bit operating system required, System Requirement: 400 Watt or greater power supply (Recommended) 1 x 6-pin Power Connector PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with.
