TD1607 özellikleri ve fiyatları

TD1607 teknik özellikleri

Model kodu

TD1607

Ekran boyutu

15.6 inç

Ekran çözünürlüğü

1920 x 1080

Ekran teknolojisi

IPS Technology

Ekran yenileme hızı

60 Hz

maximum Refresh Rate Conditions

Refresh Rate (Hz): 60; Frequency Horizontal: mini HDMI (v1.4): 15 ~ 82KHz, Type C: 24 ~ 82KHz; Frequency Vertical: mini HDMI (v1.4): 50 ~ 75Hz, Type C: 50 ~ 75Hz; Digital Sync: TMDS - mini HDMI (v1.4), Micro-Packet - Type C

resolution Conditions

Resolution: 1920 x 1080; Refresh Rate (Hz): 60; Frequency Horizontal: mini HDMI (v1.4): 15 ~ 82KHz, Type C: 24 ~ 82KHz; Frequency Vertical: mini HDMI (v1.4): 50 ~ 75Hz, Type C: 50 ~ 75Hz; Digital Sync: TMDS - mini HDMI (v1.4), Micro-Packet - Type C

Çözünürlük standardı

FHD (Full HD)

contrast Ratio

1,000:1 (typ)

Ekran oranı

16:9

Ekran renk sayısı

16.7M

viewing Angle

178º horizontal, 178º vertical

screen Curvature

Flat

screen Finish

Glossy, Hard Coating (3H)

Ekran koruması

3H

Renk gamı

NTSC: 45% size (Typ) sRGB: 65% size (Typ)

vesa Mount

Customized, 75 mm

tilt

20º / 30º

power Supply Type

External (Optional)

Tepe parlaklık

250 nit

Tipik parlaklık

250 nit

response Time

7

response Time Method

Typical GtG

power Consumption

8

power Standby

0.5

Ağırlık

800 g

Boyutlar

Packaging (mm): 435 x 284 x 88; Physical (mm): 355.5 x 210.8 x 12.6; Physical Without Stand (mm): 355.5 x 210.8 x 12.6

ports

USB 3.2 Type C Up Stream; DisplayPort Alt mode: 2 (65W power charger), 3.5mm Audio Out: 1, Mini HDMI: 1, Power in: USB Type C (with video & data)

usb Power Delivery Watts

65

Ses çıkışı

3.5mm Audio Out: 1

Hoparlör özellikleri

Internal Speakers: 1Watts x2

Stereo hoparlör

Var

stand Adjustments

Tilt (Forward/Back): 20º / 30º

ergonomic Features

Tilt (Forward/Back): 20º / 30º

Ekran özellikleri

Light Source: LED, Color Space Support: 8 bit (6 bit + FRC), Response Time (Typical GTG): 7ms, Response Time (GTG w/OD): 7ms, Response Time (Typical Tr+Tf): 20ms, Backlight Life (Hours): 50000 Hrs (Min), Low Blue Light: Software solution, Flicker-Free: Yes, Pixel Size: 0.179 mm (H) x 0.179 mm (V), Touch Screen: Projected Capacitive, 10-point multi-touch

Kutu içeriği

TD1607 x1, USB Type-C Gen2 Cable (Male-Male) x1, Quick Start Guide x1, Sleeve case x1

Üreticinin ayrıntılı teknik bilgileri

Display / Display Size (in.): 16; Display / Viewable Area (in.): 15.6; Display / Panel Type: IPS Technology; Display / Resolution: 1920 x 1080; Display / Resolution Type: FHD (Full HD); Display / Static Contrast Ratio: 1,000:1 (typ); Display / Dynamic Contrast Ratio: 50M:1; Display / Light Source: LED; Display / Brightness: 250 cd/m² (typ); Display / Colors: 16.7M; Display / Color Space Support: 8 bit (6 bit + FRC); Display / Aspect Ratio: 16:9; Display / Response Time (Typical GTG): 7ms; Display / Response Time (GTG w/OD): 7ms; Display / Response Time (Typical Tr+Tf): 20ms; Display / Viewing Angles: 178º horizontal, 178º vertical; Display / Backlight Life (Hours): 50000 Hrs (Min); Display / Glass thickness: 0.58mm; Display / Glass Hardness: 3H; Display / Curvature: Flat; Display / Refresh Rate (Hz): 60; Display / Low Blue Light: Software solution; Display / Flicker-Free: Yes; Display / Color Gamut: NTSC: 45% size (Typ) sRGB: 65% size (Typ); Display / Pixel Size: 0.179 mm (H) x 0.179 mm (V); Display / Touch Screen: Projected Capacitive, 10-point multi-touch; Display / Surface Treatment: Glossy, Hard Coating (3H); Display / Cover Glass Thickness: 0.58mm; Compatibility / PC Resolution (max): 1920x1080; Compatibility / Mac® Resolution (max): 1920x1080; Compatibility / PC Operating System: Windows 10/11 certified; macOS tested; Compatibility / Mac® Resolution (min): 1920x1080; Connector / USB 3.2 Type C Up Stream; DisplayPort Alt mode: 2 (65W power charger), Connector / 3.5mm Audio Out: 1; Connector / Mini HDMI: 1; Connector / Power in: USB Type C (with video & data); Audio / Internal Speakers: 1Watts x2; Power / Eco Mode (Conserve): 6W; Power / Eco Mode (optimized): 7.5W; Power / Consumption (typical): 8W; Power / Consumption (max): 8.5W; Power / Voltage: DC 5V/9V/12V/15V/20V; Power / Stand-by: 0.5W; Power / Power Supply: External (Optional); Controls / Physical Controls: Lever push key: Up, Enter, Down, Return (power); Controls / On Screen Display: Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu; Operating Conditions / Temperature: 32°F to 104°F (0°C to 40°C); Operating Conditions / Humidity (non-condensing): 20% to 90%; Wall Mount / VESA Compatible: Customized, 75 mm; Input Signal / Frequency Horizontal: mini HDMI (v1.4): 15 ~ 82KHz, Type C: 24 ~ 82KHz; Input Signal / Frequency Vertical: mini HDMI (v1.4): 50 ~ 75Hz, Type C: 50 ~ 75Hz; Video Input / Digital Sync: TMDS - mini HDMI (v1.4), Micro-Packet - Type C; Ergonomics / Tilt (Forward/Back): 20º / 30º; Weight (imperial) / Net (lbs): 1.8; Weight (imperial) / Net Without Stand (lbs): 1.8; Weight (imperial) / Gross (lbs): 4.4; Weight (metric) / Net (kg): 0.8; Weight (metric) / Net Without Stand (kg): 0.8; Weight (metric) / Gross (kg): 2; Dimensions (imperial) (wxhxd) / Packaging (in.): 17.1 x 11.2 x 3.5; Dimensions (imperial) (wxhxd) / Physical (in.): 14 x 8.3 x 0.5; Dimensions (imperial) (wxhxd) / Physical Without Stand (in.): 14 x 8.3 x 0.5, Dimensions (metric) (wxhxd) / Packaging (mm): 435 x 284 x 88; Dimensions (metric) (wxhxd) / Physical (mm): 355.5 x 210.8 x 12.6; Dimensions (metric) (wxhxd) / Physical Without Stand (mm): 355.5 x 210.8 x 12.6; General / Regulations: BSMI; General / PACKAGE CONTENTS: TD1607 x1, USB Type-C Gen2 Cable (Male-Male) x1, Quick Start Guide x1, Sleeve case x1; General / Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.; General / Warranty: *Warranty offered may differ from market to market

technical Details Continued

Overview heading: 16” Full HD Multi-Touch Portable Monitor with USB-C and Mini HDMI, Manufacturer feature: Compact, lightweight, and designed for effortless portability, Manufacturer feature: Full HD (1920x1080) IPS display with 60Hz refresh rate, Manufacturer feature: 10-point multi-touch* technology offering intuitive screen control, Manufacturer feature: USB-C one-cable solution for audio, visual, touch, and power delivery, Manufacturer feature: Magnetic protective cover that turns into an adjustable stand *To enable the touch function on macOS, please download vTouch **External power adaptor required for power charging
