VA24E1-H özellikleri ve fiyatları

VA24E1-H teknik özellikleri

Model kodu

VA24E1-H

Ekran boyutu

23.8 inç

Ekran çözünürlüğü

1920 x 1080

Ekran teknolojisi

IPS Technology

Ekran yenileme hızı

120 Hz

maximum Refresh Rate Conditions

Refresh Rate (Hz): 120; Frequency Horizontal: RGB Analog: 24 ~ 86KHz, HDMI (v1.4): 30 ~ 145KHz; Frequency Vertical: RGB Analog: 48 ~ 75Hz, HDMI (v1.4): 48 ~ 120Hz; Digital Sync: TMDS - HDMI (v1.4); Analog Sync: Separate - RGB Analog

resolution Conditions

Resolution: 1920 x 1080; Refresh Rate (Hz): 120; Frequency Horizontal: RGB Analog: 24 ~ 86KHz, HDMI (v1.4): 30 ~ 145KHz; Frequency Vertical: RGB Analog: 48 ~ 75Hz, HDMI (v1.4): 48 ~ 120Hz; Digital Sync: TMDS - HDMI (v1.4); Analog Sync: Separate - RGB Analog

Çözünürlük standardı

FHD (Full HD)

contrast Ratio

1,500:1 (typ)

Ekran oranı

16:9

Ekran renk sayısı

16.7M

viewing Angle

178º horizontal, 178º vertical

screen Curvature

Flat

screen Finish

Anti-Glare, Hard Coating (3H)

Renk gamı

NTSC: 77% size (Typ) sRGB: 109% size (Typ)

vesa Mount

75 x 75 mm

tilt

-5º / 15º

power Supply Type

External Power Adaptor

Tepe parlaklık

250 nit

Tipik parlaklık

250 nit

response Time

5

response Time Method

Typical GtG

power Consumption

21

power Standby

0.5

Ağırlık

2300 g

Boyutlar

Packaging (mm): 604 x 393 x 120; Physical (mm): 539.24 x 404.71 x 200; Physical Without Stand (mm): 539.24 x 315.06 x 34

ports

VGA: 1, HDMI 1.4: 1, Power in: DC Socket (Center Positive)

HDMI bağlantı sayısı

1 adet

HDMI sürümü

HDMI 1.4: 1

stand Adjustments

Tilt (Forward/Back): -5º / 15º

ergonomic Features

Tilt (Forward/Back): -5º / 15º

Ekran özellikleri

Light Source: LED, Color Space Support: 8 bit (6 bit + FRC), Response Time (Typical GTG): 5ms, Backlight Life (Hours): 30000 Hrs (Min), Low Blue Light: Software solution, Pixel Size: 0.275 mm (H) x 0.275 mm (V)

Kutu içeriği

VA24E1-H x1, HDMI Cable (v1.4; Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1, Power plug x1 or 2 (by country)

Üreticinin ayrıntılı teknik bilgileri

Display / Display Size (in.): 24; Display / Viewable Area (in.): 23.8; Display / Panel Type: IPS Technology; Display / Resolution: 1920 x 1080; Display / Resolution Type: FHD (Full HD); Display / Static Contrast Ratio: 1,500:1 (typ); Display / Dynamic Contrast Ratio: 3M:1; Display / Light Source: LED; Display / Brightness: 250 cd/m² (typ); Display / Colors: 16.7M; Display / Color Space Support: 8 bit (6 bit + FRC); Display / Aspect Ratio: 16:9; Display / Response Time (Typical GTG): 5ms; Display / Viewing Angles: 178º horizontal, 178º vertical; Display / Backlight Life (Hours): 30000 Hrs (Min); Display / Curvature: Flat; Display / Refresh Rate (Hz): 120; Display / Low Blue Light: Software solution; Display / Color Gamut: NTSC: 77% size (Typ) sRGB: 109% size (Typ); Display / Pixel Size: 0.275 mm (H) x 0.275 mm (V); Display / Surface Treatment: Anti-Glare, Hard Coating (3H); Compatibility / PC Resolution (max): 1920x1080; Compatibility / Mac® Resolution (max): 1920x1080; Compatibility / PC Operating System: Windows 10/11 certified; macOS tested; Compatibility / Mac® Resolution (min): 1920x1080; Connector / VGA: 1; Connector / HDMI 1.4: 1; Connector / Power in: DC Socket (Center Positive); Power / Eco Mode (Conserve): 14W; Power / Eco Mode (optimized): 15W; Power / Consumption (typical): 21W; Power / Consumption (max): 24W; Power / Voltage: AC 100-240V; Power / Stand-by: 0.5W; Power / Power Supply: External Power Adaptor, Controls / Physical Controls: Up, Right, Down, Left, Power; Controls / On Screen Display: Input Select, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu; Operating Conditions / Temperature: 32°F to 104°F (0°C to 40°C); Operating Conditions / Humidity (non-condensing): 20% to 90%; Wall Mount / VESA Compatible: 75 x 75 mm; Input Signal / Frequency Horizontal: RGB Analog: 24 ~ 86KHz, HDMI (v1.4): 30 ~ 145KHz; Input Signal / Frequency Vertical: RGB Analog: 48 ~ 75Hz, HDMI (v1.4): 48 ~ 120Hz; Video Input / Digital Sync: TMDS - HDMI (v1.4); Video Input / Analog Sync: Separate - RGB Analog; Ergonomics / Tilt (Forward/Back): -5º / 15º; Weight (imperial) / Net (lbs): 5.1; Weight (imperial) / Net Without Stand (lbs): 4.6; Weight (imperial) / Gross (lbs): 7.7; Weight (metric) / Net (kg): 2.3; Weight (metric) / Net Without Stand (kg): 2.1; Weight (metric) / Gross (kg): 3.5; Dimensions (imperial) (wxhxd) / Packaging (in.): 23.8 x 15.5 x 4.7; Dimensions (imperial) (wxhxd) / Physical (in.): 21.23 x 15.93 x 7.87; Dimensions (imperial) (wxhxd) / Physical Without Stand (in.): 21.23 x 12.4 x 1.34; Dimensions (metric) (wxhxd) / Packaging (mm): 604 x 393 x 120; Dimensions (metric) (wxhxd) / Physical (mm): 539.24 x 404.71 x 200; Dimensions (metric) (wxhxd) / Physical Without Stand (mm): 539.24 x 315.06 x 34; General / Regulations: CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, General / PACKAGE CONTENTS: VA24E1-H x1, HDMI Cable (v1.4; Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1, Power plug x1 or 2 (by country); General / Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.; General / Warranty: *Warranty offered may differ from market to market
