VG2242 özellikleri ve fiyatları

VG2242 teknik özellikleri

Model kodu

VG2242

Ekran boyutu

21.5 inç

Ekran çözünürlüğü

1920 x 1080

Ekran teknolojisi

VA Technology

Ekran yenileme hızı

120 Hz

maximum Refresh Rate Conditions

Refresh Rate (Hz): 120; Frequency Horizontal: RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 24 ~ 110KHz, DisplayPort (v1.2): 24 ~ 110KHz; Frequency Vertical: RGB Analog: 50 ~ 75Hz, HDMI (v1.4): 50 ~ 120Hz, DisplayPort (v1.2): 50 ~ 120Hz; Digital Sync: TMDS - HDMI (v1.4), Micro-Packet - DisplayPort (v1.2); Analog Sync: Separate/Composite/SOG - RGB Analog

resolution Conditions

Resolution: 1920 x 1080; Refresh Rate (Hz): 120; Frequency Horizontal: RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 24 ~ 110KHz, DisplayPort (v1.2): 24 ~ 110KHz; Frequency Vertical: RGB Analog: 50 ~ 75Hz, HDMI (v1.4): 50 ~ 120Hz, DisplayPort (v1.2): 50 ~ 120Hz; Digital Sync: TMDS - HDMI (v1.4), Micro-Packet - DisplayPort (v1.2); Analog Sync: Separate/Composite/SOG - RGB Analog

Çözünürlük standardı

FHD (Full HD)

contrast Ratio

4,000:1 (typ)

Ekran oranı

16:9

Ekran renk sayısı

16.7M

viewing Angle

178º horizontal, 178º vertical

screen Curvature

Flat

screen Finish

Anti-Glare, Hard Coating (3H)

Ekran koruması

3H

Renk gamı

NTSC: 72% size (Typ) sRGB: 104% size (Typ)

vesa Mount

100 x 100 mm

tilt

-5º / 21º

pivot

90º / 90º

height Adjustment

150

power Supply Type

Internal Power Supply

Tepe parlaklık

250 nit

Tipik parlaklık

250 nit

response Time

5

response Time Method

Typical GtG

power Consumption

17

power Standby

0.5

Ağırlık

4100 g

Boyutlar

Packaging (mm): 595 x 400 x 198; Physical (mm): 493.13 x 381.29~501.63 x 229.55; Physical Without Stand (mm): 493.13 x 282.01 x 46

ports

VGA: 1, USB 3.2 Type A Down Stream: 4, USB 3.2 Type B Up Stream: 1, 3.5mm Audio In: 1, 3.5mm Audio Out: 1, HDMI 1.4: 1, DisplayPort: 1, Power in: 3-pin Socket (IEC C14 / CEE22)

HDMI bağlantı sayısı

1 adet

HDMI sürümü

HDMI 1.4: 1

DisplayPort bağlantı sayısı

1 adet

DisplayPort sürümü

Frequency Horizontal: RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 24 ~ 110KHz, DisplayPort (v1.2): 24 ~ 110KHz; Frequency Vertical: RGB Analog: 50 ~ 75Hz, HDMI (v1.4): 50 ~ 120Hz, DisplayPort (v1.2): 50 ~ 120Hz; Digital Sync: TMDS - HDMI (v1.4), Micro-Packet - DisplayPort (v1.2)

Ses çıkışı

3.5mm Audio Out: 1

Hoparlör özellikleri

Internal Speakers: 2Watts x2

Stereo hoparlör

Var

stand Adjustments

Height Adjust (mm): 150; Swivel: 90º; Tilt (Forward/Back): -5º / 21º; Pivot (Right/Left): 90º / 90º

ergonomic Features

Height Adjust (mm): 150; Swivel: 90º; Tilt (Forward/Back): -5º / 21º; Pivot (Right/Left): 90º / 90º

Ekran özellikleri

Light Source: LED, Color Space Support: 8 bit (6 bit + FRC), Response Time (Typical GTG): 5ms, Response Time (GTG w/OD): 5ms, Backlight Life (Hours): 30000 Hrs (Min), Low Blue Light: Hardware solution, Flicker-Free: Yes, Pixel Size: 0.249 mm (H) x 0.241 mm (V)

Kutu içeriği

VG2242-1T x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v1.4; Male-Male) x1, USB A/B Cable (v3.2; Male-Male) x1, Quick Start Guide x1

Üreticinin ayrıntılı teknik bilgileri

Display / Display Size (in.): 22; Display / Viewable Area (in.): 21.5; Display / Panel Type: VA Technology; Display / Resolution: 1920 x 1080; Display / Resolution Type: FHD (Full HD); Display / Static Contrast Ratio: 4,000:1 (typ); Display / Dynamic Contrast Ratio: 80M:1; Display / Light Source: LED; Display / Brightness: 250 cd/m² (typ); Display / Colors: 16.7M; Display / Color Space Support: 8 bit (6 bit + FRC); Display / Aspect Ratio: 16:9; Display / Response Time (Typical GTG): 5ms; Display / Response Time (GTG w/OD): 5ms; Display / Viewing Angles: 178º horizontal, 178º vertical; Display / Backlight Life (Hours): 30000 Hrs (Min); Display / Glass Hardness: 3H; Display / Curvature: Flat; Display / Refresh Rate (Hz): 120; Display / Low Blue Light: Hardware solution; Display / Flicker-Free: Yes; Display / Color Gamut: NTSC: 72% size (Typ) sRGB: 104% size (Typ); Display / Pixel Size: 0.249 mm (H) x 0.241 mm (V); Display / Surface Treatment: Anti-Glare, Hard Coating (3H); Compatibility / PC Resolution (max): 1920x1080; Compatibility / Mac® Resolution (max): 1920x1080; Compatibility / PC Operating System: Windows 10/11 certified; macOS tested; Compatibility / Mac® Resolution (min): 1920x1080; Connector / VGA: 1; Connector / USB 3.2 Type A Down Stream: 4; Connector / USB 3.2 Type B Up Stream: 1; Connector / 3.5mm Audio In: 1; Connector / 3.5mm Audio Out: 1; Connector / HDMI 1.4: 1; Connector / DisplayPort: 1; Connector / Power in: 3-pin Socket (IEC C14 / CEE22), Audio / Internal Speakers: 2Watts x2; Power / Eco Mode (Conserve): 13W; Power / Eco Mode (optimized): 15W; Power / Consumption (typical): 17W; Power / Consumption (max): 18.5W; Power / Voltage: AC 100-240V; Power / Stand-by: 0.5W; Power / Power Supply: Internal Power Supply; Additional Hardware / Kensington Lock Slot: 1; Additional Hardware / Cable Organization: Yes; Controls / Physical Controls: Joystick key: Up, Right, Down, Left, Center; Shortcut, Power; Controls / On Screen Display: Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu; Operating Conditions / Temperature: 32°F to 104°F (0°C to 40°C); Operating Conditions / Humidity (non-condensing): 20% to 90%; Wall Mount / VESA Compatible: 100 x 100 mm; Input Signal / Frequency Horizontal: RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 24 ~ 110KHz, DisplayPort (v1.2): 24 ~ 110KHz; Input Signal / Frequency Vertical: RGB Analog: 50 ~ 75Hz, HDMI (v1.4): 50 ~ 120Hz, DisplayPort (v1.2): 50 ~ 120Hz; Video Input / Digital Sync: TMDS - HDMI (v1.4), Micro-Packet - DisplayPort (v1.2); Video Input / Analog Sync: Separate/Composite/SOG - RGB Analog; Ergonomics / Height Adjust (mm): 150; Ergonomics / Swivel: 90º; Ergonomics / Tilt (Forward/Back): -5º / 21º; Ergonomics / Pivot (Right/Left): 90º / 90º; Weight (imperial) / Net (lbs): 9; Weight (imperial) / Net Without Stand (lbs): 5.4; Weight (imperial) / Gross (lbs): 15.1; Weight (metric) / Net (kg): 4.1; Weight (metric) / Net Without Stand (kg): 2.5, Weight (metric) / Gross (kg): 6.8; Dimensions (imperial) (wxhxd) / Packaging (in.): 23.4 x 15.7 x 7.8; Dimensions (imperial) (wxhxd) / Physical (in.): 19.41 x 15.01~19.74 x 9.04; Dimensions (imperial) (wxhxd) / Physical Without Stand (in.): 19.41 x 11.1 x 1.81; Dimensions (metric) (wxhxd) / Packaging (mm): 595 x 400 x 198; Dimensions (metric) (wxhxd) / Physical (mm): 493.13 x 381.29~501.63 x 229.55; Dimensions (metric) (wxhxd) / Physical Without Stand (mm): 493.13 x 282.01 x 46; General / Regulations: cSGSus, FCC-B, ICES003, Energy Star, EPEAT; General / PACKAGE CONTENTS: VG2242-1T x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v1.4; Male-Male) x1, USB A/B Cable (v3.2; Male-Male) x1, Quick Start Guide x1; General / Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.; General / Warranty: *Warranty offered may differ from market to market; General / Power Management: Energy Star standards, EPEAT

technical Details Continued

Overview heading: 22” Full HD Ergonomic Business Monitor, Manufacturer feature: 120Hz Refresh rate delivers fluid visuals, Manufacturer feature: Eye ProTech+ for always-on eye protection, Manufacturer feature: Ergonomic tilt, swivel, pivot, and height adjustment capabilities, Manufacturer feature: Dual speakers for clear audio, Manufacturer feature: HDMI, DisplayPort, VGA, and USB3.2 ports for extended connectivity
