Canon imagePROGRAF TC-21 özellikleri ve fiyatları

Canon imagePROGRAF TC-21 teknik özellikleri

Model kodu

imagePROGRAF TC-21

part Number

7055C003

printing Technology

Canon Pigment ink 4 colours integrated type (4 chips per print head x 1 print head)

functions

Print (manufacturer product classification: Large Format Printers)

print Resolution

2,400 x 1,200 dpi

print Languages

N/A (no direct print supported)

consumables

Pigment inks : 4 colour BK/C/M/Y

power Supply Type

AC 100-240V (50-60Hz)

operating Temperature

Temperature: 15~30℃, Humidity: 10~80% RH (no dew condensation)

noise Conditions

Power and Operating Requirements / Acoustic Noise (Power/Pressure): Operation: Approx. 41.5 dB(A) / (Plain paper, Standard mode, Line Drawing/Text mode) / Standby: 35 dB(A) or less / (Measured on ISO 7779 standard) / / Operation: Approx. 6.0 Bels / (Standard Plain Paper, Standard mode, Line Drawing/Text mode) / (Measured on ISO 7779 standard)

power Consumption Conditions

Power and Operating Requirements / Power Consumption: Operation: Approx. 28W / Sleep mode: Approx. 2.3W / Default setting for the time to enter the Sleep mode: Approx. 5 minutes / Power off: Approx. 0.07W

color Printing

Var

Boyutlar

W x D x H / Main Unit / 968 x 533 x 245 mm (ASF closed, operation panel not tilted) / 968 x 593 x 245 mm (ASF closed, operation panel tilted) / 968 x 613 x 395 mm (ASF opened, operation panel tilted) / 32 kg (exclude ink bottle, include print head) / / Main Unit + Desktop Basket (BU-06) / 968 x 595 x 965* mm / (ASF closed, operation panel not tilted, basket closed) / 968 x 845 x 1115* mm / (ASF opened, operation panel tilted, basket opened) / 33 kg (exclude ink bottle, include print head) / / Main Unit + Stand + Basket (SD-24) / 968 × 720 × 874 mm / (ASF closed, operation panel not tilted, basket closed) / 968 × 868 × 1024 mm / (ASF opened, operation panel tilted, basket opened) / 43 kg (exclude ink bottle, include print head) / / *Height above which cloth does not touch the floor when opening the desktop basket.

paper Formats

Media Width: Roll paper : A3, A2, A2+, A1, B2, B3, 18'', 24'', 17'' / Cut sheet: A3, A4, A5, A6, B4, B5, B6, C4, Ledger, Letter, Legal, Foolscap, Executive, ARCH A, Photo (10"x12", 10"x15", 8"X10", 7"X10", 5"x7", 4"x6"(KG), 2L, L), Envelope (Com 10, DL, C5, Monarch), B-Oficio, M-Oficio, user-defined size (width: 89 mm - 297mm, length: 127mm - 1200mm)

Üreticinin ayrıntılı teknik bilgileri

Printer Technology / Printer Type: 4 Colour 24" | Printer Technology / Print Technology: Canon Pigment ink 4 colours integrated type (4 chips per print head x 1 print head) | Printer Technology / Print Resolution: 2,400 x 1,200 dpi | Printer Technology / Number of Nozzles: Total : 4352 nozzles BK : 1280 nozzles C, M, Y : 1024 nozzles each | Printer Technology / Line Accuracy: ±0.1% or less / User adjustments necessary. Printing environment and media must match those used for the adjustments. | Printer Technology / Nozzle Pitch: 1,200 dpi x 2 lines | Printer Technology / Ink Capacity: Bundled Starter Ink: 280ml (70mlx4 for BK, C, M, Y) / Sales Ink: 70ml (BK, C, M, Y) | Printer Technology / Ink Type: Pigment inks : 4 colour BK/C/M/Y | Printer Technology / OS Compatibility: 32 Bit: Windows7, Windows 8.1, Windows 10 / 64 Bit: Windows 7, Windows 8.1, Windows 10, Windows 11, / Windows Server 2008R2, 2012, 2012R2, 2016, 2019, 2022, 2025 / Apple Macintosh: macOS 11.7.10~macOS 14.15 | Printer Technology / Other Supported Job Submission Protocols: Apple AirPrint, Mopria, Chrome OS | Printer Technology / Printer Languages: N/A (no direct print supported) | Printer Technology / Standard Interfaces: USB A Port: N/A / USB B Port: Hi-Speed USB / Ethernet: IEEE802.3u(100BASE-TX) / IEEE802.3(10BASE-T) / Wireless LAN*: IEEE802.11n/IEEE802.11g/IEEE802.11b/IEEE802.11a/ IEEE802.11ac / / *Please refer to user manual how to activate/deactivate the, wireless LAN | Memory / Standard Memory: 1GB / Expansion slot : No | Memory / Hard Drive: N/A | Print Speed / CAD Drawing: Plain paper (A1, B&W): / 0:30 (Standard) / Plain Paper (A1, Colour): / 1:00 (Standard) | Print Speed / Poster: Plain Paper (A1) / 1:01 (Draft) / 1:51 (Standard) / / Coated Paper (A1) / 2:42 (Draft) / 4:23 (Standard) | Media Handling / Media Feed and Output: Roll Paper : One Roll, Front-loading, Front Output / Cut Sheet : Auto sheet feeder, Face-up, Front side | Media Handling / Media Width: Roll paper : A3, A2, A2+, A1, B2, B3, 18'', 24'', 17'' / Cut sheet: A3, A4, A5, A6, B4, B5, B6, C4, Ledger, Letter, Legal, Foolscap, Executive, ARCH A, Photo (10"x12", 10"x15", 8"X10", 7"X10", 5"x7", 4"x6"(KG), 2L, L), Envelope (Com 10, DL, C5, Monarch), B-Oficio, M-Oficio, user-defined size (width: 89 mm - 297mm, length: 127mm - 1200mm) | Media Handling / Media Thickness: Roll/Cut : 0.08mm - 0.28mm | Media Handling / Minimum Printable Length: Roll paper: 203.2mm / Cut sheet: 127mm | Media Handling / Maximum Printable Length: Roll paper : 4m / Cut sheet : 1200mm | Media Handling / Maximum Media Roll Diameter: 110mm | Media Handling / Media Core Size: Internal diameter of roll core: 2" | Media Handling / Margins Recommended Area: Roll paper: Top: 5mm, Bottom: 5mm, Side: 5mm / (some photo mode: Top: 30mm, Bottom: 30mm) / Cut sheet: Top: 5mm, Bottom: 5mm, Side: 5mm | Media Handling / Margins Printable Area: Roll paper:, Top: 5mm, Bottom: 5mm, Side: 5mm / (some photo mode: Top: 30mm, Bottom: 30mm) / Roll paper (minimal margin print): Top: 0mm, Bottom: 0mm, Side: Approx. 0.5mm / Cut sheet: Top: 5mm, Bottom: 5mm, Side: 5mm | Media Handling / Media Feed Capacity: Roll Paper: One roll / Cut Sheet: A4, Letter: 100 sheets (plain paper) / A3, B4, Ledger, Legal, 10" x 12", 10" x 15": 50 sheets (plain paper) / FS, Foolscap, ARCH A, C4, B-OFICIO, M-OFICIO: 10 sheets (plain paper) / Others: 1 sheet | Media Handling / Media Take-Up Roll Unit: N/A | Media Handling / Borderless Printing Width (Roll Only): A4, A3, A2, A1, B4, B3, B2, 17”, 18”, 24” / Top/Bottom: Fully borderless; Left/Right: Approx. 0.5mm margin | Media Handling / Maximum Number of Delivered Prints: Stand Basket (SD-24) / Desktop Basket (BU-06): Standard position - 1 sheet | Power and Operating Requirements / Power Supply: AC 100-240V (50-60Hz) | Power and Operating Requirements / Power Consumption: Operation: Approx. 28W / Sleep mode: Approx. 2.3W / Default setting for the time to enter the Sleep mode: Approx. 5 minutes / Power off: Approx. 0.07W | Power and Operating Requirements / Operating Environment: Temperature: 15~30℃, Humidity: 10~80% RH (no dew condensation) | Power and Operating Requirements / Acoustic Noise (Power/Pressure): Operation: Approx. 41.5 dB(A) / (Plain paper, Standard mode, Line Drawing/Text mode) / Standby: 35 dB(A) or less / (Measured on ISO 7779 standard) / /, Operation: Approx. 6.0 Bels / (Standard Plain Paper, Standard mode, Line Drawing/Text mode) / (Measured on ISO 7779 standard) | Power and Operating Requirements / Regulations: CE mark, UKCA mark | Power and Operating Requirements / Environment Certificates: CB certfication, EPEAT GOLD | Dimensions and Weight / Physical Dimensions and Weight: W x D x H / Main Unit / 968 x 533 x 245 mm (ASF closed, operation panel not tilted) / 968 x 593 x 245 mm (ASF closed, operation panel tilted) / 968 x 613 x 395 mm (ASF opened, operation panel tilted) / 32 kg (exclude ink bottle, include print head) / / Main Unit + Desktop Basket (BU-06) / 968 x 595 x 965* mm / (ASF closed, operation panel not tilted, basket closed) / 968 x 845 x 1115* mm / (ASF opened, operation panel tilted, basket opened) / 33 kg (exclude ink bottle, include print head) / / Main Unit + Stand + Basket (SD-24) / 968 × 720 × 874 mm / (ASF closed, operation panel not tilted, basket closed) / 968 × 868 × 1024 mm / (ASF opened, operation panel tilted, basket opened) / 43 kg (exclude ink bottle, include print head) / / *Height above which cloth does not touch the floor when opening the desktop basket. | Dimensions and Weight / Packaged Dimensions and Weight: Printer (Main unit): 1120 x 726 x 406 mm, 45kg / Desktop Basket (BU-06): 798 x 301 x 111 mm, 2.0kg / Stand + Basket (SD-24): 1058 x 826 x 270 mm, 20kg | What's Included / What's in the Box?: Printer, 1 Print head, Power, Cable, 1 Set of starter ink tanks, 1 Roll holder (shaftless), Installation Guide, Safety and Environmental Information, LFP Eur Address Sheet, Notice for PosterArtist WEB US/EU, Flange protective materials sheet | What's Included / Software Included: Software available as Download from Web | Options / Optional Items: Desktop Basket: BU-06 / Printer Stand and Basket: SD-24 | Consumables / User Replaceable Items: Ink Tank: PFl-050 (70ml) / Print Head: PF-08 / Maintenance Cartridge: MC-32 | Manufacturer technical note / footnote-1: Compare to predecessor model, imagePROGRAF TC-20 | Manufacturer technical note / footnote-2: EPEAT Gold registered in the U.S
