TP-Link TL-SG1008MP özellikleri ve fiyatları

TP-Link TL-SG1008MP teknik özellikleri

Model kodu

TL-SG1008MP

Anahtar türü

Unmanaged

Ethernet bağlantıları

8 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX

Desteklenen ağ kabloları

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)

İletim yöntemi

Store-And-Forward

Jumbo çerçeve

16 KB

Güç kaynağı

100-240VAC, 50/60Hz

Güç tüketimi koşulları

• 8.77 W(220V/50Hz. no PD connected)• 172.49 W(110V/60Hz. with 153W PD connected)

En yüksek ısı yayılımı

• 29.91 BTU/h(no PD connected)• 588.19 BTU/h(with 153W PD connected)

Boyutlar

11.6*7.1*1.7 in. (294*180*44 mm)

Kurulum biçimi

Desktop/Rack Mountable

Soğutma fanları

Fanless

Sertifikalar

FCC, CE

Kutu içeriği

TL-SG1008MP, Power Cord, Installation Guide, Rackmount Kit, Rubber Feet

Ek anahtarlama özellikleri

• Compatible With IEEE 802.3af/at Compliant PDs• Priority Function• Mac Address Auto-Learning And Auto-Aging• IEEE802.3x Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex Mode• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)• PoE Auto Recovery (Ports 1-8)

Fiziksel güvenlik

No

RJ45 bağlantıları

8 port

Fansız tasarım

Var

Paket iletme hızı

11.904 Mpps

PoE güç koşulları

Standard: 802.3af/at compliantPoE+ Ports: 8 PortsPower Supply: 153W

PoE desteği

Var

Anahtarlama kapasitesi

16 Gbps

Çalışma sıcaklığı

0℃~45℃ (32℉~113℉)

Saklama sıcaklığı

-40℃~70℃ (-40℉~158℉)

Çalışma nemi

10%~90% non-condensing

Depolama nemi

5%~90% non-condensing

Üreticinin ayrıntılı teknik bilgileri

Interface: 8 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX, Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m), Fan Quantity: Fanless, Physical Security Lock: No, Power Supply: 100-240VAC, 50/60Hz, Packet Forwarding Rate: 11.904 Mpps, PoE Ports (RJ45): Standard: 802.3af/at compliantPoE+ Ports: 8 PortsPower Supply: 153W, Mac Address Table: 4K, Buffer Size: 1.5Mbits, Jumbo Frame: 16 KB, Switching Capacity: 16Gbps, Dimensions ( W x D x H ): 11.6*7.1*1.7 in. (294*180*44 mm), Mounting: Desktop/Rack Mountable, Max. Power Consumption: • 8.77 W(220V/50Hz. no PD connected)• 172.49 W(110V/60Hz. with 153W PD connected), Max Heat Dissipation: • 29.91 BTU/h(no PD connected)• 588.19 BTU/h(with 153W PD connected), Advanced Features: • Compatible With IEEE 802.3af/at Compliant PDs• Priority Function• Mac Address Auto-Learning And Auto-Aging• IEEE802.3x Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex Mode• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)• PoE Auto Recovery (Ports 1-8), Transmission Method: Store-And-Forward, Certification: FCC, CE, Package Content: TL-SG1008MP, Power Cord, Installation Guide, Rackmount Kit, Rubber Feet, Environment: Operating Temperature: 0℃~45℃ (32℉~113℉)Storage Temperature: -40℃~70℃ (-40℉~158℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing
