PRIME A320I-K özellikleri ve fiyatları

PRIME A320I-K teknik özellikleri

Model kodu

PRIME A320I-K

İşlemci soketi

AM4

Anakart yonga seti

AMD A320

Anakart biçimi

Mini ITX

RAM türü

DDR4

Uyumlu işlemciler

AMD AM4 Socket for 3rd/2nd/1st Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics/Athlon with Radeon Vega Graphics/7 th Generation A-series/Athlon X4 Processors; Supports CPU up to 8 cores; * Refer to www.asus.com for CPU support list

Desteklenen bellek yapılandırmaları

3rd and 2nd Gen AMD Ryzen Processors; 2 x DIMM, Max. 64GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory; AMD Ryzen with Radeon Vega Graphics/ Ryzen 1st Generation Processors; 2 x DIMM, Max. 64GB, DDR4 3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory; AMD 7th Generation A-series/Athlon Processors; 2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz ECC and non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).

RAM yuvası sayısı

2

Desteklenen en yüksek RAM

64 GB

Bellek kanalı sayısı

2 kanal

PCIe yuvaları

3rd/2nd/1st Gen AMD Ryzen Processors; 1 x PCIe 3.0/2.0 x16 (x16 mode); AMD Ryzen with Radeon Vega Graphics /7th Generation A-Series/Athlon X4 Processors; 1 x PCIe 3.0/2.0 x16 (x8 mode); AMD Athlon with Radeon Vega Graphics Processors; 1 x PCIe 3.0/2.0 x16 (x4 mode)

PCIe şerit paylaşımı ve işlemci koşulları

3rd/2nd/1st Gen AMD Ryzen Processors; 1 x PCIe 3.0/2.0 x16 (x16 mode); AMD Ryzen with Radeon Vega Graphics /7th Generation A-Series/Athlon X4 Processors; 1 x PCIe 3.0/2.0 x16 (x8 mode); AMD Athlon with Radeon Vega Graphics Processors; 1 x PCIe 3.0/2.0 x16 (x4 mode)

M.2 uyumluluğu ve şerit paylaşımı

3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics :; 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode); AMD 7th Generation A-Series/ Athlon X4 Processors :; 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA mode); AMD Athlon with Radeon Vega Graphics Processors :; 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA mode); AMD A320 chipset :; 4 x SATA 6Gb/s port(s), gray,; Support Raid 0, 1, 10

RAID desteği

Support Raid 0, 1, 10

Ses çıkışı

Realtek ALC887/897 8-Channel High Definition Audio CODEC; - Supports : Front Panel Jack-retasking, up to 24-Bit/192kHz playback; Audio Feature :; - Audio Shielding; - Dedicated audio PCB layers; - Premium Japanese audio capacitors; * Choose the chassis with HD audio module in front panel to support 8-channel audio output.

Ses yongası

Realtek ALC887/897 8-Channel High Definition Audio CODEC

Ses kanalı yapılandırması

8 kanal

BIOS özellikleri

128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information

Diğer anakart özellikleri

ASUS 5X Protection III :; - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage; - ASUS Overvoltage Protection: World-class circuit-protecting power design; - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!; - ASUS DIGI+ VRM: Premium components provide better power efficiency; - ASUS ESD Guards - Enhanced ESD protection; ASUS EPU :; - EPU; AURA :; - Aura Lighting Control; - Aura RGB Strip Headers; ASUS Exclusive Features :; - AI Suite 3; - Ai Charger; ASUS Quiet Thermal Solution :; - Stylish Fanless Design Heat-sink solution; - ASUS Fan Xpert 2+; ASUS EZ DIY :; - ASUS CrashFree BIOS 3; - ASUS EZ Flash 3; - ASUS UEFI BIOS EZ Mode; ASUS Q-Design :; - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED); - ASUS Q-Slot; - ASUS Q-DIMM

Boyutlar

Mini ITX Form Factor; 6.7 inch x 6.7 inch ( 17 cm x 17 cm )

Kutu içeriği

User´s manual; I/O Shield; 2 x SATA 6Gb/s cable(s); 1 x M.2 Screw Package; 1 x Supporting DVD; 1 x M.2 bracket

Üreticinin ayrıntılı teknik bilgileri

Model: PRIME A320I-K, CPU: AMD AM4 Socket for 3rd/2nd/1st Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics/Athlon with Radeon Vega Graphics/7 th Generation A-series/Athlon X4 Processors Supports CPU up to 8 cores * Refer to www.asus.com for CPU support list, Chipset: AMD A320, Memory: 3rd and 2nd Gen AMD Ryzen Processors 2 x DIMM, Max. 64GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory AMD Ryzen with Radeon Vega Graphics/ Ryzen 1st Generation Processors 2 x DIMM, Max. 64GB, DDR4 3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory AMD 7th Generation A-series/Athlon Processors 2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz ECC and non-ECC, Un-buffered Memory Dual Channel Memory Architecture * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists)., Graphic: Integrated Graphics in the AMD Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics/ 7th Generation A-Series APU Multi-VGA output support : HDMI/DisplayPort ports - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz - Supports DisplayPort with max. resolution 4096 x 2160 @ 60 Hz Maximum shared memory of 2048 MB (for iGPU exclusively), Expansion Slots: 3rd/2nd/1st Gen AMD Ryzen Processors 1 x PCIe 3.0/2.0 x16 (x16 mode) AMD Ryzen with Radeon Vega Graphics /7th Generation A-Series/Athlon X4 Processors 1 x PCIe 3.0/2.0 x16 (x8 mode) AMD Athlon with Radeon Vega Graphics Processors 1 x PCIe 3.0/2.0 x16 (x4 mode), Storage: 3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics : 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) AMD 7th Generation A-Series/ Athlon X4 Processors : 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA mode) AMD Athlon with Radeon Vega Graphics Processors : 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA mode) AMD A320 chipset : 4 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 10, LAN: Realtek RTL8111H, 1 x Gigabit LAN Controller(s) ASUS LAN Guard, Audio: Realtek ALC887/897 8-Channel High Definition Audio CODEC - Supports : Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature : - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors * Choose the chassis with HD audio module in front panel to support 8-channel audio output., USB Ports: 3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics/ 7th Generation A-series/ Athlon X4 Processors : 4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue) AMD A320 chipset : 2 x USB 3.0 port(s) (2 at mid-board) AMD A320 chipset : 4 x USB 2.0 port(s) (2 at back panel, black, 2 at mid-board), Special Features: ASUS 5X Protection III : - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage - ASUS Overvoltage Protection: World-class circuit-protecting power design - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! - ASUS DIGI+ VRM: Premium components provide better power efficiency - ASUS ESD Guards - Enhanced ESD protection ASUS EPU : - EPU AURA : - Aura Lighting Control - Aura RGB Strip Headers ASUS Exclusive Features : - AI Suite 3 - Ai Charger ASUS Quiet Thermal Solution : - Stylish Fanless Design Heat-sink solution - ASUS Fan Xpert 2+ ASUS EZ DIY : - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode ASUS Q-Design : - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-Slot - ASUS Q-DIMM, Back I/O Ports: 1 x PS/2 keyboard/mouse combo port(s) 1 x DisplayPort 1 x HDMI 1 x LAN (RJ45) port(s) 4 x USB 3.1 Gen 1 (blue) 2 x USB 2.0 3 x Audio jack(s), Internal I/O Ports: 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) (1 x 4 -pin) 2 x Chassis Fan connector(s) (1 x 4 -pin) 2 x Aura RGB Strip Headers 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) (19-pin) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x TPM header 4 x SATA 6Gb/s connector(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) 1 x Clear CMOS jumper(s), Accessories: User´s manual I/O Shield 2 x SATA 6Gb/s cable(s) 1 x M.2 Screw Package 1 x Supporting DVD 1 x M.2 bracket, BIOS: 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information, Operating System: Windows 10 64-bit, Form Factor: Mini ITX Form Factor 6.7 inch x 6.7 inch ( 17 cm x 17 cm )
