ROG RAMPAGE VI APEX özellikleri ve fiyatları

ROG RAMPAGE VI APEX teknik özellikleri

Model kodu

ROG RAMPAGE VI APEX

İşlemci soketi

Intel Socket 2066

Anakart yonga seti

Intel X299

Anakart biçimi

ATX

RAM türü

DDR4

Uyumlu işlemciler

Optimized for Intel Core X-Series 10000 Processor Family; Intel Socket 2066 Core X-Series Processors; Supports Intel Virtual RAID on CPU (VROC); * The Intel Turbo Boost Max Technology 3.0 support depends on the CPU types; * Refer to www.asus.com for CPU support list

Desteklenen bellek yapılandırmaları

4 x DIMM, Max. 128GB, DDR4 4133(O.C.)/4000(O.C.)/3866(O.C.)/3800(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2600(O.C.)/2400/2133 MHz Non-ECC, Un-buffered Memory; 4 x DIMM, Max. 128GB, DDR4 4500(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory; 4 x DIMM, Max. 128GB, DDR4 4500(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2933/2666/2400/2133 MHz Non-ECC, Un-buffered Memory; Intel Core X-series Processors (4-core); Intel Core X-series Processors (6-core above)

RAM yuvası sayısı

4

Desteklenen en yüksek RAM

128 GB

PCIe yuvaları

4 x PCIe 3.0 x16 (x16, x16/x8, x16/x8/x8/x4 with CPU_DIMM.2_1&_2 X4 mode or x16/x8/x8/x8 mode with 40-lane CPU,x16, x16/x8 with CPU_DIMM.2_1 X4 mode with 28-lane cpu); Intel Core X-Series Processors Family; Intel X299 Chipset; 1 x PCIe 3.0 x4

PCIe şerit paylaşımı ve işlemci koşulları

4 x PCIe 3.0 x16 (x16, x16/x8, x16/x8/x8/x4 with CPU_DIMM.2_1&_2 X4 mode or x16/x8/x8/x8 mode with 40-lane CPU,x16, x16/x8 with CPU_DIMM.2_1 X4 mode with 28-lane cpu); Intel Core X-Series Processors Family; Intel X299 Chipset; 1 x PCIe 3.0 x4

M.2 uyumluluğu ve şerit paylaşımı

1 x ROG DIMM.2 Module support(CPU_DIMM.2)*1,; 2 x M.2 Socket 3*1, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode); 1 x M.2 Socket 3*2, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode); 1 x M.2 Socket 3*2, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode); 1 x ROG DIMM.2 Module support(PCH_DIMM.2)*2; ASMedia ASM1061 controller :; Supports Intel Smart Response Technology; Intel Core X-Series Processors Family :; Intel X299 Chipset :; 2 x SATA 6Gb/s port(s),; 4 x SATA 6Gb/s port(s); Intel Optane Memory Ready

Ses çıkışı

- Supports : Jack-detection; ROG SupremeFX8-Channel High Definition Audio CODEC S1220A; - Impedance sense for front and rear headphone outputs; - SupremeFX Shielding Technology; - Supports up to 32-Bit/192kHz playback

Ses yongası

ROG SupremeFX8-Channel High Definition Audio CODEC S1220A

BIOS özellikleri

2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS,; ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log,; F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information.

Diğer anakart özellikleri

- ASUS DIGI+ VRM: 8 Phase digital power design; SafeDIMM slot; OC Design - ASUS PRO Clock II Technology; - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED, HDD LED); 5-Way Optimization by Dual Intelligent Processors 5; - Whole system optimization with a single click! 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo App together, providing better CPU performance, efficient power saving, precise digital power control, whole system cooling and even tailor your own app usages.; ASUS 5X Protection III :; - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage; - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!; - ASUS Overvoltage Protection: World-class circuit-protecting power design; Gamer´s Guardian:; - DRAM Overcurrent Protection; - Digi+ VRM; - SafeSlot; ASUS EPU :; AURA :; - Aura Lighting Control; - Aura RGB Strip Headers; - Aura Lighting Effects Synchronization with compatible ASUS ROG devices; ASUS Exclusive Features :; - AI Suite 3; ASUS Quiet Thermal Solution :; - ASUS Fan Xpert 4; ASUS EZ DIY :; - ASUS MyLogo; ASUS Q-Design :; - ASUS Q-Shield; - ASUS Q-Code; - ASUS Q-Connector; Gaming Aesthetics :; - 3D printing friendly; - AURA-RGB Lighting

Boyutlar

12 inch x 10.7 inch ( 30.5 cm x 27.2 cm ) X-SHAPED PCB; Extended ATX Form Factor

Kutu içeriği

Accessory Guide; 4 x M.2 screws; 1 x R6A MOS Fan bracket pack; 2 x ROG DIMM.2 Fan Stand Pack (s); 1 x 10 in 1 ROG Cable Label(s); 1 x 3-Way SLI bridge(s); 1 x 4-Way SLI bridge(s); 1 x SLI HB BRIDGE(2-WAY-L); User´s manual; I/O Shield; 4 x SATA 6Gb/s cable(s); 1 x Supporting DVD; 1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant); 1 x ROG big sticker; 1 x Q-Connector; 1 x ROG coaster(s)

Üreticinin ayrıntılı teknik bilgileri

Model: ROG RAMPAGE VI APEX, CPU: Optimized for Intel Core X-Series 10000 Processor Family Intel Socket 2066 Core X-Series Processors Supports Intel Virtual RAID on CPU (VROC) * The Intel Turbo Boost Max Technology 3.0 support depends on the CPU types * Refer to www.asus.com for CPU support list, Chipset: Intel X299, Memory: 4 x DIMM, Max. 128GB, DDR4 4133(O.C.)/4000(O.C.)/3866(O.C.)/3800(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2600(O.C.)/2400/2133 MHz Non-ECC, Un-buffered Memory 4 x DIMM, Max. 128GB, DDR4 4500(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory 4 x DIMM, Max. 128GB, DDR4 4500(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2933/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Intel Core X-series Processors (4-core) Intel Core X-series Processors (6-core above), Multi-GPU Support: Supports NVIDIA 4-Way SLI Technology Supports NVIDIA 3-Way SLI Technology Supports NVIDIA 2-Way SLI Technology Supports AMD 4-Way CrossFireX Technology Supports AMD 3-Way CrossFireX Technology Supports AMD 2-Way CrossFireX Technology, Expansion Slots: 4 x PCIe 3.0 x16 (x16, x16/x8, x16/x8/x8/x4 with CPU_DIMM.2_1&_2 X4 mode or x16/x8/x8/x8 mode with 40-lane CPU,x16, x16/x8 with CPU_DIMM.2_1 X4 mode with 28-lane cpu) Intel Core X-Series Processors Family Intel X299 Chipset 1 x PCIe 3.0 x4, Storage: 1 x ROG DIMM.2 Module support(CPU_DIMM.2)*1, 2 x M.2 Socket 3*1, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) 1 x M.2 Socket 3*2, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) 1 x M.2 Socket 3*2, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x ROG DIMM.2 Module support(PCH_DIMM.2)*2 ASMedia ASM1061 controller : Supports Intel Smart Response Technology Intel Core X-Series Processors Family : Intel X299 Chipset : 2 x SATA 6Gb/s port(s), 4 x SATA 6Gb/s port(s) Intel Optane Memory Ready, LAN: Dual interconnect between the integrated Media Access Controller (MAC) and physical layer (PHY) Intel I219V Anti-surge LANGuard, Wireless Data Network: Wi-Fi 802.11 a/b/g/n/ac Supports dual band frequency 2.4/5 GHz Supports MU-MIMO, Bluetooth: Bluetooth V4.2, Audio: - Supports : Jack-detection ROG SupremeFX8-Channel High Definition Audio CODEC S1220A - Impedance sense for front and rear headphone outputs - SupremeFX Shielding Technology - Supports up to 32-Bit/192kHz playback, USB Ports: 6 x USB 3.1 Gen 1 port(s) (4 at mid-board) 5 x USB 2.0 port(s) (3 at mid-board) 4 x USB 3.1 Gen 1 port(s) Intel X299 Chipset : 1 x USB 3.1 Gen 2 front panel connector port(s) ASMedia USB 3.1 Gen 2 controller : ASMedia USB 3.1 Gen 1 controller : 2 x USB 3.1 Gen 2 port(s), ROG Exclusive Features: MemOK! Button ROG RAMCache II - O.C. Profile Clear CMOS button ROG CloneDrive Slow Mode ReTry Button Safe Boot Button LN2 Mode Mem TweakIt - PCIe x16 Lane Switch Double Power : - Dual 8-pin CPU ProbeIt ROG CPU-Z Overwolf Start Button Reset Button ROG Aura Extreme Engine Digi+ : - IR3555 PoweIRstage - MicroFine Alloy Chokes - 10K Black Metallic Capacitors ROG Extreme OC kit : UEFI BIOS features : - Tweakers´ Paradise - ROG SSD Secure Erase Extreme Tweaker USB BIOS Flashback, Special Features: - ASUS DIGI+ VRM: 8 Phase digital power design SafeDIMM slot OC Design - ASUS PRO Clock II Technology - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED, HDD LED) 5-Way Optimization by Dual Intelligent Processors 5 - Whole system optimization with a single click! 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo App together, providing better CPU performance, efficient power saving, precise digital power control, whole system cooling and even tailor your own app usages. ASUS 5X Protection III : - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges! - ASUS Overvoltage Protection: World-class circuit-protecting power design Gamer´s Guardian: - DRAM Overcurrent Protection - Digi+ VRM - SafeSlot ASUS EPU : AURA : - Aura Lighting Control - Aura RGB Strip Headers - Aura Lighting Effects Synchronization with compatible ASUS ROG devices ASUS Exclusive Features : - AI Suite 3 ASUS Quiet Thermal Solution : - ASUS Fan Xpert 4 ASUS EZ DIY : - ASUS MyLogo ASUS Q-Design : - ASUS Q-Shield - ASUS Q-Code - ASUS Q-Connector Gaming Aesthetics : - 3D printing friendly - AURA-RGB Lighting, Operating System Support: Windows 10, Back I/O Ports: 1 x USB 3.1 Gen 2 (), 2 x USB 3.1 Gen 2 (red)Type-A + USB Type-CTM 1 x ASUS 2x2 Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.2 module 6 x USB 3.1 Gen 1 1 x PS/2 keyboard (purple) 1 x PS/2 mouse (green) 1 x LAN (RJ45) port(s) 2 x USB 2.0 1 x Optical S/PDIF out 1 x Clear CMOS button(s) 1 x USB BIOS Flashback Button(s) 5 x Gold-plated audio jacks, Internal I/O Ports: 1 x AAFP connector 1 x USB 2.0 connector(s) support(s) additional 1 USB 2.0 port(s) 2 x 8-pin EATX 12V Power connector 5 x 4-pin Full Speed Fan connectors 1 x 3D Mount screw port(s) 1 x ROG extension (ROG_EXT) header(s) 1 x Q_Code 9 x ProbeIt Measurement Points 1 x MemOK! button(s) 1 x VROC_HW_Key 1 x EZ Plug connector(s) (4-pin Molex power connector) 1 x BIOS Switch button(s) 2 x T_Sensor Connector 1 x USB 3.1 Gen 2 front panel connector 2 x DIMM.2 Slot supports 2 M.2 drives (2242-22110) 1 x PCIe x16 lane switch 2 x RSVD Switch 2 x Aura RGB Strip Headers 2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) 1 x TPM header 6 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 1 x AIO_PUMP connector 1 x W_PUMP+ connector 1 x 24-pin EATX Power connector(s) 2 x 8-pin ATX 12V Power connector(s) 1 x Slow Mode switch(es) 1 x Power-on button(s) 1 x Reset button(s) 1 x LN2 Mode jumper(s) 1 x Safe Boot button 1 x ReTry button 1 x W_IN header 1 x W_OUT header 1 x W_FLOW header, Accessories: Accessory Guide 4 x M.2 screws 1 x R6A MOS Fan bracket pack 2 x ROG DIMM.2 Fan Stand Pack (s) 1 x 10 in 1 ROG Cable Label(s) 1 x 3-Way SLI bridge(s) 1 x 4-Way SLI bridge(s) 1 x SLI HB BRIDGE(2-WAY-L) User´s manual I/O Shield 4 x SATA 6Gb/s cable(s) 1 x Supporting DVD 1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant) 1 x ROG big sticker 1 x Q-Connector 1 x ROG coaster(s), BIOS: 2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information., Operating System: Windows 10 64-bit, Form Factor: 12 inch x 10.7 inch ( 30.5 cm x 27.2 cm ) X-SHAPED PCB Extended ATX Form Factor, Note: *1 USB2.0 PORT SHARE WITH ROG_EXT HEADER

part Number

90MB0UC0-M0AAY0

Güncel mağaza teklifleri

Son 48 saat içinde doğrulanmış, stokta mağaza teklifi yok. Eski fiyatlar güncel teklif olarak gösterilmez.
