TUF GAMING B550M-PLUS özellikleri ve fiyatları

TUF GAMING B550M-PLUS teknik özellikleri

Model kodu

TUF GAMING B550M-PLUS

İşlemci soketi

AM4

Anakart yonga seti

AMD B550

Anakart biçimi

Micro-ATX

RAM türü

DDR4

Uyumlu işlemciler

* Refer to www.asus.com for CPU support list.,AMD AM4 Socket for AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors *

Desteklenen bellek yapılandırmaları

* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.,4 x DIMM, Max. 128GB, DDR4 4866(O.C)/4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4333(O.C.)/4266(O.C.)/4200(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory *,ECC Memory (ECC mode) support varies by CPU.,Dual Channel Memory Architecture

RAM yuvası sayısı

4

Desteklenen en yüksek RAM

128 GB

Bellek kanalı sayısı

2 kanal

PCIe yuvaları

AMD Ryzen 5000 G-Series/ 4000 G-Series Desktop Processors , AMD Ryzen 5000 Series/ 3000 Series Desktop Processors ,* Support PCIe bifurcation for RAID on CPU function., AMD B550 Chipset ,1 x PCIe 3.0 x16 (x4 mode),1 x PCIe 4.0 x16 (x16 mode),1 x PCIe 3.0 x1,1 x PCIe 3.0 x16 (x16 mode)

PCIe şerit paylaşımı ve işlemci koşulları

AMD Ryzen 5000 G-Series/ 4000 G-Series Desktop Processors , AMD Ryzen 5000 Series/ 3000 Series Desktop Processors ,* Support PCIe bifurcation for RAID on CPU function., AMD B550 Chipset ,1 x PCIe 3.0 x16 (x4 mode),1 x PCIe 4.0 x16 (x16 mode),1 x PCIe 3.0 x1,1 x PCIe 3.0 x16 (x16 mode)

M.2 uyumluluğu ve şerit paylaşımı

AMD Ryzen 5000 G-Series/ 4000 G-Series Desktop Processors : , AMD Ryzen 5000 Series/ 3000 Series Desktop Processors : ,1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support, Total supports 2 x M.2 slot(s) and 4 x SATA 6Gb/s ports , AMD B550 Chipset : ,4 x SATA 6Gb/s port(s),,Support Raid 0, 1, 10,1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support,1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support

RAID desteği

AMD Ryzen 5000 G-Series/ 4000 G-Series Desktop Processors : , AMD Ryzen 5000 Series/ 3000 Series Desktop Processors : ,1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support, Total supports 2 x M.2 slot(s) and 4 x SATA 6Gb/s ports , AMD B550 Chipset : ,4 x SATA 6Gb/s port(s),,Support Raid 0, 1, 10,1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support,1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support

Depolama için M.2 yuvası sayısı

2

SATA bağlantı sayısı

4

Ses çıkışı

- Premium audio capacitors,Realtek ALC S1200A7.1 Surround Sound High Definition Audio CODEC,- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback,- Audio Shielding,- Dedicated audio PCB layers,- Audio Cover, Audio Feature : ,- Exclusive DTS Custom for GAMING Headsets.,- Optical S/PDIF out port(s) at back panel

Ses yongası

- Premium audio capacitors,Realtek ALC S1200A7.1 Surround Sound High Definition Audio CODEC,- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback,- Audio Shielding,- Dedicated audio PCB layers,- Audio Cover, Audio Feature : ,- Exclusive DTS Custom for GAMING Headsets.,- Optical S/PDIF out port(s) at back panel

Ses kanalı yapılandırması

7.1 kanal

BIOS özellikleri

256 Mb Flash ROM, UEFI AMI BIOS

Boyutlar

mATX Form Factor,9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )

Kutu içeriği

1 x M.2 SSD screw package(s),1 x M.2 Rubber Package(s),2 x SATA 6Gb/s cable(s),User´s manual,I/O Shield,1 x Supporting DVD,1 x TUF GAMING Sticker,1 x TUF Certification card(s),2 x SATA 6Gb/s cable(s)

Üreticinin ayrıntılı teknik bilgileri

Model: TUF GAMING B550M-PLUS, CPU: * Refer to www.asus.com for CPU support list.,AMD AM4 Socket for AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors *, Chipset: AMD B550, Memory: * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.,4 x DIMM, Max. 128GB, DDR4 4866(O.C)/4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4333(O.C.)/4266(O.C.)/4200(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory *,ECC Memory (ECC mode) support varies by CPU.,Dual Channel Memory Architecture, Graphic: 1 x HDMI 2.1(4K@60HZ),1 x DisplayPort 1.2,*Graphics specifications may vary between CPU types., Multi-GPU Support: Supports AMD 2-Way CrossFireX Technology, Expansion Slots: AMD Ryzen 5000 G-Series/ 4000 G-Series Desktop Processors , AMD Ryzen 5000 Series/ 3000 Series Desktop Processors ,* Support PCIe bifurcation for RAID on CPU function., AMD B550 Chipset ,1 x PCIe 3.0 x16 (x4 mode),1 x PCIe 4.0 x16 (x16 mode),1 x PCIe 3.0 x1,1 x PCIe 3.0 x16 (x16 mode), Storage: AMD Ryzen 5000 G-Series/ 4000 G-Series Desktop Processors : , AMD Ryzen 5000 Series/ 3000 Series Desktop Processors : ,1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support, Total supports 2 x M.2 slot(s) and 4 x SATA 6Gb/s ports , AMD B550 Chipset : ,4 x SATA 6Gb/s port(s),,Support Raid 0, 1, 10,1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support,1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support, LAN: Realtek RTL8125B 2.5Gb Ethernet,TUF LANGuard, Audio: - Premium audio capacitors,Realtek ALC S1200A7.1 Surround Sound High Definition Audio CODEC,- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback,- Audio Shielding,- Dedicated audio PCB layers,- Audio Cover, Audio Feature : ,- Exclusive DTS Custom for GAMING Headsets.,- Optical S/PDIF out port(s) at back panel, USB Ports: 4 x USB 2.0 port(s)(4 x Type-A), Front USB Port ( Total 6 ), Rear USB Port ( Total 8 ),4 x USB 3.2 Gen 1 port(s)(4 x Type-A),2 x USB 3.2 Gen 1 port(s)(2 x Type-A),2 x USB 2.0 port(s)(2 x Type-A),2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C ), Software Features: ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - AI Noise Cancelling Microphone AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert 2+ - EZ update TUF GAMING CPU-Z AI Charger ASUS Turbo LAN DAEMON Tools DTS Custom for GAMING Headsets Norton Anti-virus software (Free Trial for 60 days) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode, ASUS Special Features: ASUS TUF PROTECTION - ASUS DIGI+ VRM (Digital power design with Dr. MOS) - ASUS Enhanced DRAM Overcurrent Protection - ASUS ESD Guards - TUF LANGuard - ASUS Overvoltage Protection - ASUS SafeSlot - ASUS Stainless-Steel Back I/O ASUS Q-Design - ASUS Q-DIMM - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - ASUS Q-Slot ASUS Thermal Solution - Aluminum M.2 heatsink ASUS EZ DIY - BIOS FlashBack button - BIOS FlashBack LED - Procool AURA Sync - Standard RGB headers - Addressable Gen 2 RGB header, Back I/O Ports: 4 x USB 3.2 Gen 1 (blue) (one port can be switched to USB BIOS FlashBack ),2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C ),1 x BIOS FlashBack Button(s),1 x LAN (2.5G) port(s),1 x PS/2 keyboard/mouse combo port(s),1 x DisplayPort,1 x HDMI,2 x USB 2.0,1 x Optical S/PDIF out,5 x Audio jack(s), Internal I/O Ports: 1 x COM port header,1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s),1 x CPU Fan connector(s),1 x CPU OPT Fan connector(s),2 x Chassis Fan connector(s),2 x Aura RGB Strip Headers,1 x Addressable Gen 2 header(s),2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s),1 x SPI TPM header,4 x SATA 6Gb/s connector(s),1 x 24-pin EATX Power connector(s),1 x 8-pin EATX 12V Power connectors,1 x Front panel audio connector(s) (AAFP),1 x Clear CMOS jumper(s),1 x System panel connector,1 x COM port header,1 x Speaker connector,1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode),1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode), Accessories: 1 x M.2 SSD screw package(s),1 x M.2 Rubber Package(s),2 x SATA 6Gb/s cable(s),User´s manual,I/O Shield,1 x Supporting DVD,1 x TUF GAMING Sticker,1 x TUF Certification card(s),2 x SATA 6Gb/s cable(s), BIOS: 256 Mb Flash ROM, UEFI AMI BIOS, Manageability: WOL by PXE, Operating System: Windows 10 64-bit, Form Factor: mATX Form Factor,9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
