MS-Challenger B850M-B WIFI özellikleri ve fiyatları

MS-Challenger B850M-B WIFI teknik özellikleri

Model kodu

MS-Challenger B850M-B WIFI

İşlemci soketi

AM5

Uyumlu işlemciler

AMD® AM5 socket for AMD® Ryzen™ 7000, 8000 and 9000 Series processors

Anakart yonga seti

AMD® B850 chipset

Anakart biçimi

Micro-ATX

Boyutlar

Micro-ATX (245 × 215 mm)

RAM türü

DDR5

Desteklenen bellek yapılandırmaları

2 × DDR5 DIMM slots, up to 128 GB Dual-channel memory architecture Supports memory overclocking Supported speeds: 4800 / 5600 (OC) / 6000 (OC) / 6200 (OC) / 6400 (OC) / 6600 (OC) / 6800 (OC) / 7000 (OC) / 7200 (OC) / 7400 (OC) / 7600 (OC) / 7800 (OC) / 8000 (OC) MHz

Bellek hızı ve uyumluluk koşulları

2 × DDR5 DIMM slots, up to 128 GB Dual-channel memory architecture Supports memory overclocking Supported speeds: 4800 / 5600 (OC) / 6000 (OC) / 6200 (OC) / 6400 (OC) / 6600 (OC) / 6800 (OC) / 7000 (OC) / 7200 (OC) / 7400 (OC) / 7600 (OC) / 7800 (OC) / 8000 (OC) MHz

RAM yuvası sayısı

2

Desteklenen en yüksek RAM

128 GB

Bellek kanalı sayısı

2 kanal

PCIe yuvaları

From AMD Ryzen™ 9000/8000/7000 processor: 1 × PCIe x16 slot, up to PCIe 5.0 x16 Ryzen™ 7000/9000 Series: PCIe 5.0 x16 Ryzen™ 8000 Series: PCIe 4.0 x8/x4 From AMD B850 chipset: 1 × PCIe x16 slot, supports PCIe 4.0 x4 1 × PCIe x1 slot, supports PCIe 3.0 x1

PCIe şerit paylaşımı ve işlemci koşulları

From AMD Ryzen™ 9000/8000/7000 processor: 1 × PCIe x16 slot, up to PCIe 5.0 x16 Ryzen™ 7000/9000 Series: PCIe 5.0 x16 Ryzen™ 8000 Series: PCIe 4.0 x8/x4 From AMD B850 chipset: 1 × PCIe x16 slot, supports PCIe 4.0 x4 1 × PCIe x1 slot, supports PCIe 3.0 x1

storage Interfaces

2 × M.2 slots and 2 × SATA 6Gb/s ports From AMD Ryzen™ 9000/8000/7000 processor: M.2_A (Key M), supports PCIe 5.0 x4/x2 and 2242/2280 devices Ryzen™ 7000/9000 Series: PCIe 5.0 x4 Ryzen™ 8000 Series: PCIe 4.0 x4/x2 From AMD B850 chipset: M.2_B (Key M), supports PCIe 4.0 x4/x2 and 2242/2280 devices 2 × SATA 6Gb/s ports

M.2 uyumluluğu ve şerit paylaşımı

2 × M.2 slots and 2 × SATA 6Gb/s ports From AMD Ryzen™ 9000/8000/7000 processor: M.2_A (Key M), supports PCIe 5.0 x4/x2 and 2242/2280 devices Ryzen™ 7000/9000 Series: PCIe 5.0 x4 Ryzen™ 8000 Series: PCIe 4.0 x4/x2 From AMD B850 chipset: M.2_B (Key M), supports PCIe 4.0 x4/x2 and 2242/2280 devices 2 × SATA 6Gb/s ports

Depolama için M.2 yuvası sayısı

2

SATA bağlantı sayısı

2

Kablolu ağ bağlantısı

1 × Realtek® RTL8125 2.5Gb Ethernet 1 × MediaTek MT7902 wireless module with Wi-Fi 6 and Bluetooth® 5.2

Wi-Fi

1 × Realtek® RTL8125 2.5Gb Ethernet 1 × MediaTek MT7902 wireless module with Wi-Fi 6 and Bluetooth® 5.2

Bluetooth sürümü

5.2

USB bağlantısı

Front/internal (7 ports total): 1 × USB-C® 20Gbps header for 1 front USB-C® 20Gbps port 1 × USB 5Gbps 19-pin header for 2 additional USB 5Gbps ports 2 × USB 2.0 9-pin headers for 4 additional USB 2.0 ports Rear (8 ports total): 4 × USB 5Gbps Type-A 4 × USB 2.0 Type-A

Dahili bağlantılar ve ön panel başlıkları

1 × 24-pin ATX power connector 1 × 8-pin +12V CPU power connector 1 × 4-pin CPU fan header 1 × 4-pin pump header with DC speed control 2 × 4-pin chassis fan headers

Güç bağlantıları

1 × 24-pin ATX power connector 1 × 8-pin +12V CPU power connector 1 × 4-pin CPU fan header 1 × 4-pin pump header with DC speed control 2 × 4-pin chassis fan headers

Görüntü çıkışları ve kullanım koşulları

Available when using a processor with integrated graphics 1 × HDMI™ 2.0, up to 4K at 60 Hz 2 × DisplayPort, up to 4K at 60 Hz

Ses çıkışı

Realtek® ALC897 audio codec

Ses yongası

ALC897

Diğer anakart özellikleri

CLR_CMOS button 3 × 3-pin ARGB headers 1 × 4-pin NRGB header 1 × COM header 1 × 10-1 pin system panel header MAXSUN Sync lighting control

Üreticinin ayrıntılı teknik bilgileri

Model: MS-Challenger B850M-B WIFI, Form Factor: Micro-ATX (245 × 215 mm), CPU Support: AMD® AM5 socket for AMD® Ryzen™ 7000, 8000 and 9000 Series processors, Chipset: AMD® B850 chipset, Memory: 2 × DDR5 DIMM slots, up to 128 GB Dual-channel memory architecture Supports memory overclocking Supported speeds: 4800 / 5600 (OC) / 6000 (OC) / 6200 (OC) / 6400 (OC) / 6600 (OC) / 6800 (OC) / 7000 (OC) / 7200 (OC) / 7400 (OC) / 7600 (OC) / 7800 (OC) / 8000 (OC) MHz, Integrated Graphics: Available when using a processor with integrated graphics 1 × HDMI™ 2.0, up to 4K at 60 Hz 2 × DisplayPort, up to 4K at 60 Hz, Expansion Slots: From AMD Ryzen™ 9000/8000/7000 processor: 1 × PCIe x16 slot, up to PCIe 5.0 x16 Ryzen™ 7000/9000 Series: PCIe 5.0 x16 Ryzen™ 8000 Series: PCIe 4.0 x8/x4 From AMD B850 chipset: 1 × PCIe x16 slot, supports PCIe 4.0 x4 1 × PCIe x1 slot, supports PCIe 3.0 x1, Audio: Realtek® ALC897 audio codec, Networking: 1 × Realtek® RTL8125 2.5Gb Ethernet 1 × MediaTek MT7902 wireless module with Wi-Fi 6 and Bluetooth® 5.2, Storage: 2 × M.2 slots and 2 × SATA 6Gb/s ports From AMD Ryzen™ 9000/8000/7000 processor: M.2_A (Key M), supports PCIe 5.0 x4/x2 and 2242/2280 devices Ryzen™ 7000/9000 Series: PCIe 5.0 x4 Ryzen™ 8000 Series: PCIe 4.0 x4/x2 From AMD B850 chipset: M.2_B (Key M), supports PCIe 4.0 x4/x2 and 2242/2280 devices 2 × SATA 6Gb/s ports, USB: Front/internal (7 ports total): 1 × USB-C® 20Gbps header for 1 front USB-C® 20Gbps port 1 × USB 5Gbps 19-pin header for 2 additional USB 5Gbps ports 2 × USB 2.0 9-pin headers for 4 additional USB 2.0 ports Rear (8 ports total): 4 × USB 5Gbps Type-A 4 × USB 2.0 Type-A, Internal Connectors: 1 × 24-pin ATX power connector 1 × 8-pin +12V CPU power connector 1 × 4-pin CPU fan header 1 × 4-pin pump header with DC speed control 2 × 4-pin chassis fan headers, Operating System: Windows® 11 Windows® 10 64-bit, Other Features: CLR_CMOS button 3 × 3-pin ARGB headers 1 × 4-pin NRGB header 1 × COM header 1 × 10-1 pin system panel header MAXSUN Sync lighting control
