MS-Challenger B860M-K özellikleri ve fiyatları

MS-Challenger B860M-K teknik özellikleri

Model kodu

MS-Challenger B860M-K

İşlemci soketi

LGA1851

Uyumlu işlemciler

Intel® LGA1851 socket, compatible with Intel® Core™ Ultra processors

Anakart yonga seti

Intel® B860 chipset

Anakart biçimi

Micro-ATX

Boyutlar

M-ATX (235 * 215 mm)

RAM türü

DDR5

Desteklenen bellek yapılandırmaları

2 DIMM DDR5 memory slots, supporting up to 96GB total Dual-channel memory technology supported Supports memory frequencies of XMP 4800/5000/5200/5400/5600/5800/6000/6200/6400/6600(OC)/6800(OC)/7000(OC)/7200(OC)/7600(OC)/8000(OC) MHz

Bellek hızı ve uyumluluk koşulları

2 DIMM DDR5 memory slots, supporting up to 96GB total Dual-channel memory technology supported Supports memory frequencies of XMP 4800/5000/5200/5400/5600/5800/6000/6200/6400/6600(OC)/6800(OC)/7000(OC)/7200(OC)/7600(OC)/8000(OC) MHz

RAM yuvası sayısı

2

Desteklenen en yüksek RAM

96 GB

Bellek kanalı sayısı

2 kanal

PCIe yuvaları

1 x PCIe x16 slot (supports PCIe 5.0 x16 mode) 1 x PCIe x1 slot (supports PCIe 4.0 x1 mode)

PCIe şerit paylaşımı ve işlemci koşulları

1 x PCIe x16 slot (supports PCIe 5.0 x16 mode) 1 x PCIe x1 slot (supports PCIe 4.0 x1 mode)

storage Interfaces

1 x M.2 slot, supports PCIe 5.0 x4/x2 modes, supports 2280 length 1 x M.2 slot, supports PCIe 4.0 x4/x2 modes, supports 2280 length 2 x SATA 6Gb/s ports

M.2 uyumluluğu ve şerit paylaşımı

1 x M.2 slot, supports PCIe 5.0 x4/x2 modes, supports 2280 length 1 x M.2 slot, supports PCIe 4.0 x4/x2 modes, supports 2280 length 2 x SATA 6Gb/s ports

SATA bağlantı sayısı

2

Kablolu ağ bağlantısı

Integrated REALTEK RTL8111M network chip

Görüntü çıkışları ve kullanım koşulları

1 HDMI port, supporting up to 4K@60Hz resolution 1 DP 1.2 port, supporting up to 4K@60Hz resolution

Ses çıkışı

Integrated REALTEK ALC897 sound chip

Ses yongası

REALTEK ALC897

Üreticinin ayrıntılı teknik bilgileri

Model: MS-Challenger B860M-K, Motherboard Size: M-ATX (235 * 215 mm), CPU Socket: Intel® LGA1851 socket, compatible with Intel® Core™ Ultra processors, Chipset: Intel® B860 chipset, Memory: 2 DIMM DDR5 memory slots, supporting up to 96GB total Dual-channel memory technology supported Supports memory frequencies of XMP 4800/5000/5200/5400/5600/5800/6000/6200/6400/6600(OC)/6800(OC)/7000(OC)/7200(OC)/7600(OC)/8000(OC) MHz, Display: 1 HDMI port, supporting up to 4K@60Hz resolution 1 DP 1.2 port, supporting up to 4K@60Hz resolution, Expansion Slots: 1 x PCIe x16 slot (supports PCIe 5.0 x16 mode) 1 x PCIe x1 slot (supports PCIe 4.0 x1 mode), Audio: Integrated REALTEK ALC897 sound chip, Network: Integrated REALTEK RTL8111M network chip, Storage: 1 x M.2 slot, supports PCIe 5.0 x4/x2 modes, supports 2280 length 1 x M.2 slot, supports PCIe 4.0 x4/x2 modes, supports 2280 length 2 x SATA 6Gb/s ports

Güncel mağaza teklifleri

Son 48 saat içinde doğrulanmış, stokta mağaza teklifi yok. Eski fiyatlar güncel teklif olarak gösterilmez.
