MS-Challenger Z890M özellikleri ve fiyatları

MS-Challenger Z890M teknik özellikleri

Model kodu

MS-Challenger Z890M

İşlemci soketi

LGA1851

Uyumlu işlemciler

Intel® LGA1851, compatible with Intel® Core™ Ultra processors

Anakart yonga seti

Intel® Z890

Anakart biçimi

Micro-ATX

Boyutlar

M-ATX (245 × 225 mm)

RAM türü

DDR5

Desteklenen bellek yapılandırmaları

2 × DIMM DDR5 slots, supporting dual-channel up to 128GB XMP frequency support up to 7200MHz (OC)

Bellek hızı ve uyumluluk koşulları

2 × DIMM DDR5 slots, supporting dual-channel up to 128GB XMP frequency support up to 7200MHz (OC)

RAM yuvası sayısı

2

Desteklenen en yüksek RAM

128 GB

Bellek kanalı sayısı

2 kanal

PCIe yuvaları

1 × PCIe x16 (supports PCIe 5.0 x16 mode) 1 × PCIe x1 (supports PCIe 4.0 x1 mode) 1 × PCIe x4 (supports PCIe 4.0 x4 mode)

PCIe şerit paylaşımı ve işlemci koşulları

1 × PCIe x16 (supports PCIe 5.0 x16 mode) 1 × PCIe x1 (supports PCIe 4.0 x1 mode) 1 × PCIe x4 (supports PCIe 4.0 x4 mode)

storage Interfaces

1 × M.2 slot (PCIe 5.0 x4/x2 mode, supports 2242/2280) 1 × M.2 slot (PCIe 4.0 x4/x2 mode, supports 2242/2280) 3 × SATA 6Gb/s ports

M.2 uyumluluğu ve şerit paylaşımı

1 × M.2 slot (PCIe 5.0 x4/x2 mode, supports 2242/2280) 1 × M.2 slot (PCIe 4.0 x4/x2 mode, supports 2242/2280) 3 × SATA 6Gb/s ports

SATA bağlantı sayısı

3

Kablolu ağ bağlantısı

Realtek RTL8125BG/D 2.5G Ethernet Intel® AX101 Wi-Fi 6 and Bluetooth 5.2

Wi-Fi

Realtek RTL8125BG/D 2.5G Ethernet Intel® AX101 Wi-Fi 6 and Bluetooth 5.2

Bluetooth sürümü

5.2

USB bağlantısı

Onboard: 1 × USB 3.2 Gen 1 (5G) header, supports 2 additional USB 3.2 Gen 1 ports 1 × USB 2.0 9-pin header, supports 2 additional USB 2.0 ports 1 × USB 3.2 Gen 2 Type-C (10G) front port Rear Panel: 4 × USB 3.2 Gen 1 Type-A (5G) ports 2 × USB 2.0 Type-A ports

Görüntü çıkışları ve kullanım koşulları

1 × HDMI™ 2.0 (4K@60Hz) 1 × DisplayPort 1.2 (4K@60Hz)

Ses çıkışı

Integrated Realtek ALC897 audio codec

Ses yongası

Realtek ALC897

Üreticinin ayrıntılı teknik bilgileri

Model: MS-Challenger Z890M, Form Factor: M-ATX (245 × 225 mm), CPU Socket: Intel® LGA1851, compatible with Intel® Core™ Ultra processors, Chipset: Intel® Z890, Memory: 2 × DIMM DDR5 slots, supporting dual-channel up to 128GB XMP frequency support up to 7200MHz (OC), Display Outputs: 1 × HDMI™ 2.0 (4K@60Hz) 1 × DisplayPort 1.2 (4K@60Hz), Expansion Slots: 1 × PCIe x16 (supports PCIe 5.0 x16 mode) 1 × PCIe x1 (supports PCIe 4.0 x1 mode) 1 × PCIe x4 (supports PCIe 4.0 x4 mode), Audio: Integrated Realtek ALC897 audio codec, Networking: Realtek RTL8125BG/D 2.5G Ethernet Intel® AX101 Wi-Fi 6 and Bluetooth 5.2, Storage: 1 × M.2 slot (PCIe 5.0 x4/x2 mode, supports 2242/2280) 1 × M.2 slot (PCIe 4.0 x4/x2 mode, supports 2242/2280) 3 × SATA 6Gb/s ports, USB Ports: Onboard: 1 × USB 3.2 Gen 1 (5G) header, supports 2 additional USB 3.2 Gen 1 ports 1 × USB 2.0 9-pin header, supports 2 additional USB 2.0 ports 1 × USB 3.2 Gen 2 Type-C (10G) front port Rear Panel: 4 × USB 3.2 Gen 1 Type-A (5G) ports 2 × USB 2.0 Type-A ports, Additional Specifications: 1 × 24 Pin ATX Power Connector 1 × 8+4 Pin +12V Power Connector 2 × 3 Pin ARGB Headers 1 × 4 Pin NRGB Header 1 × Front COM Port Header CLR CMOS Button 1 × 4 Pin CPU_FAN Header 1 × 4 Pin PUMP Header for Water Cooling 2 × 4 Pin SYS_FAN Headers for Case Fans
