PRO H410M-B özellikleri ve fiyatları

PRO H410M-B teknik özellikleri

Model kodu

PRO H410M-B

İşlemci soketi

LGA1200

Anakart yonga seti

Intel H510

Anakart biçimi

Micro-ATX

RAM türü

DDR4

Uyumlu işlemciler

Socket 1200; 10th Gen Intel Core Processors, Pentium Gold and Celeron Processors; LGA1200;

RAM yuvası sayısı

2

Desteklenen en yüksek RAM

64 GB

Bellek kanalı sayısı

2 kanal

Desteklenen bellek yapılandırmaları

1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR); Intel Extreme Memory Profile (XMP)

Bellekte hata düzeltme (ECC)

Non-ECC

Bellek tamponlama türü

Unbuffered

PCIe yuvaları

1x PCIe 3.0 x16 slot (From CPU); 1x PCIe 3.0 x1 slot (From PCH)

PCIe sürümü

PCIe 3.0

Depolama için M.2 yuvası sayısı

1

SATA bağlantı sayısı

4

M.2 uyumluluğu ve şerit paylaşımı

4x SATA 6Gb/s ports (From H510 Chipset); 1x M.2 slot (Key M, from H510 chipset); Supports up to PCIe 3.0 x4; Supports SATA 6Gb/s; Supports 2242/ 2260/ 2280 storage devices; SATA4 will be unavailable when installing M.2 SATA SSD in the; M2_1 slot.

Desteklenen M.2 boyut kodları

2242 / 2260 / 2280

M.2 bağlantı anahtarı

M-Key

USB bağlantısı

Intel H510 Chipset; 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A; ports on the back panel, 2 ports available; through the internal USB connector); 6x USB 2.0 ports (4 Type-A ports on the back; panel, 2 ports available through the internal; USB 2.0 connector)

Kablolu ağ bağlantısı

1x Realtek RTL8111 Gigabit LAN controller

Kablolu ağ denetleyicisi

1x Realtek RTL8111 Gigabit LAN controller

Ses yongası

Realtek ALC897/ ALC892 Codec

Ses kanalı yapılandırması

7.1 kanal

Ses çıkışı

Realtek ALC897/ ALC892 Codec; 7.1-Channel High Definition Audio

Dahili bağlantılar ve ön panel başlıkları

1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 4x SATA 6Gb/s connectors; 1x USB 2.0 connector (support additional 2 USB ports); 1x USB 3.2 Gen 1 5Gbps connector (support additional 2 USB ports); 1x 4-pin CPU fan connector; 1x 4-pin system fan connector; 1x Front panel audio connector; 2x System panel connectors; 1x Serial port connector; 1x TPM module connector; 1x Chassis Intrusion connector; 1x Clear CMOS jumper

Güç bağlantıları

1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector

Fan ve pompa bağlantıları

1x 4-pin CPU fan connector; 1x 4-pin system fan connector

Fan bağlantısı sayısı

2

Arka panel bağlantıları

HDMI™; VGA; Mouse / Keyboard; USB 3.2 Gen 1 5Gbps Type-A; LAN port; Audio connector; USB 2.0

Görüntü çıkışları ve kullanım koşulları

1x VGA port, supports a maximum resolution of 2048x1536 60Hz, 1920x1200 60Hz; 1x HDMI™ 1.4 port, supports a maximum resolution of 4K 30Hz; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.

TPM güvenlik modülü bağlantısı

1x TPM module connector

Boyutlar

9.3 in. x 7.95 in. (23.6 cm x 20.2 cm)

Üreticinin ayrıntılı teknik bilgileri

Processor: Supports 10th Gen Intel Core Processors,; Processor: Pentium Gold and Celeron Processors; Processor: Processor socket LGA1200; Processor: Please go to www.intel.com for more compatibility information.; Processor: See; Processor: supported; Processor: processors; Chipset: Intel H510 Chipset; Memory: 2x DDR4 memory slots, support up to 64GB; Memory: Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen; Memory: Intel CPU (by JEDEC & POR); Memory: Supports Dual-Channel mode; Memory: Supports non-ECC, un-buffered memory; Memory: Supports Intel Extreme Memory Profile (XMP); Memory: Please refer to www.msi.com for more information on compatible; Memory: memory.; Memory: See; Memory: supported memory; Expansion Slot: 1x PCIe 3.0 x16 slot (From CPU); Expansion Slot: 1x PCIe 3.0 x1 slot (From PCH); Onboard Graphics: 1x VGA port, supports a maximum resolution of; Onboard Graphics: 2048x1536 60Hz, 1920x1200 60Hz; Onboard Graphics: 1x HDMI 1.4 port, supports a maximum resolution of 4K 30Hz; Onboard Graphics: Available only on processors featuring integrated graphics.; Onboard Graphics: Graphics specifications may vary depending on the CPU installed.; Storage: 4x SATA 6Gb/s ports (From H510 Chipset); Storage: 1x M.2 slot (Key M, from H510 chipset); Storage: Supports up to PCIe 3.0 x4; Storage: Supports SATA 6Gb/s; Storage: Supports 2242/ 2260/ 2280 storage devices; Storage: SATA4 will be unavailable when installing M.2 SATA SSD in the; Storage: M2_1 slot.; USB: Intel H510 Chipset, USB: 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A; USB: ports on the back panel, 2 ports available; USB: through the internal USB connector); USB: 6x USB 2.0 ports (4 Type-A ports on the back; USB: panel, 2 ports available through the internal; USB: USB 2.0 connector); Audio: Realtek ALC897/ ALC892 Codec; Audio: 7.1-Channel High Definition Audio; LAN: 1x Realtek RTL8111 Gigabit LAN controller; Internal connectors: 1x 24-pin ATX main power connector; Internal connectors: 1x 8-pin ATX 12V power connector; Internal connectors: 4x SATA 6Gb/s connectors; Internal connectors: 1x USB 2.0 connector (support additional 2 USB ports); Internal connectors: 1x USB 3.2 Gen 1 5Gbps connector (support additional 2 USB ports); Internal connectors: 1x 4-pin CPU fan connector; Internal connectors: 1x 4-pin system fan connector; Internal connectors: 1x Front panel audio connector; Internal connectors: 2x System panel connectors; Internal connectors: 1x Serial port connector; Internal connectors: 1x TPM module connector; Internal connectors: 1x Chassis Intrusion connector; Internal connectors: 1x Clear CMOS jumper; Back panel ports: HDMI; Back panel ports: VGA; Back panel ports: Mouse / Keyboard; Back panel ports: USB 3.2 Gen 1 5Gbps Type-A; Back panel ports: LAN port; Back panel ports: Audio connector; Back panel ports: USB 2.0; Back panel ports: USB 2.0; Dimensions: m-ATX Form Factor; Dimensions: 9.3 in. x 7.95 in. (23.6 cm x 20.2 cm); Mounting: 6 mounting holes, Operating System: Support for Windows 10 64-bit; Box content: MSI does not guarantee the risks or damages caused; Box content: by changing the cover.; Box content: These pictures are for reference only and may vary without; Box content: notice.
