Cooler Master Elite 502 özellikleri ve fiyatları

Cooler Master Elite 502 teknik özellikleri

Model kodu

E502-KGNN-S00

part Number

E502-KGNN-S00

case Form Factor

Mid Tower

motherboard Support

Motherboard Support: ITX / Micro ATX / ATX (Supporting Back-connector Motherboard) / E-ATX (*up to 12"x10.9"/ 30.5cmx27.7cm motherboards, may impact cable management)

Boyutlar

Dimensions (L x W x H): 474 x 230 x 481 mm (Incl. Protrusions), 435 x 230 x 465 mm (Excl. Protrusions)

panel Materials

Materials - Exterior: Steel; Materials - Right Side Panel: Steel; Materials - Left Side Panel: TG

side Panel Material

Materials - Right Side Panel: Steel; Materials - Left Side Panel: TG

front Io

I/O Panel - USB Ports: 1x USB 3.2 Gen1 Type A, 1x USB 3.2 Gen1 Type C​; I/O Panel - Audio In / Out: 3.5 mm Combo x 1

included Fans

Pre-installed Fans - Front: 3x 120mm ARGB Fans

fan Mounts

Fan Support - Front: (Filtered) 140 mm x 3 / 120 mm x 3; Fan Support - Top: (Filtered) 140 mm x 2 / 120 mm x 3; Fan Support - Rear: 1x 120mm

radiator Support

Radiator Support - Front: 120 / 140 / 240 / 280 / 360 / 420 mm (Limit: 457*140*27 mm); Radiator Support - Top: 120 / 140 / 240 / 280 / 360mm; Radiator Support - Rear: 120mm

drive Bays

3.5" Drive Bays: 2; 2.5" Drive Bays: 2 (Max.6)

dust Filters

Dust Filters: Top, Front, Bottom

psu Support

Power Supply Support: ATX

clearance Conditions

Clearance - CPU Cooler: 170mm; Clearance - PSU: 170 / 210mm (w/o HDD Cage); Clearance - Graphics Card (installed 3.5"HDD BRK): 360 / 410 mm (w/o front radiator)

Garanti

Warranty: 2 years

case Features

Cable Routing - Behind Motherboard Tray: 33-35 mm

expansion Slots

7

cpu Cooler Max Height Mm

170

Üreticinin ayrıntılı teknik bilgileri

Product Name: ELITE 502, Product Name: ELITE 502 White, Model Number: ELITE 502: E502-KGNN-S00, Model Number: ELITE 502 White: E502-WGNN-S00, Color(s): ELITE 502: Black / ELITE 502 White: White, Materials - Exterior: Steel, Materials - Right Side Panel: Steel, Materials - Left Side Panel: TG, Dimensions (L x W x H): 474 x 230 x 481 mm (Incl. Protrusions), 435 x 230 x 465 mm (Excl. Protrusions), Volume (incl. Protrusions): 49.73 L, Motherboard Support: ITX / Micro ATX / ATX (Supporting Back-connector Motherboard) / E-ATX (*up to 12"x10.9"/ 30.5cmx27.7cm motherboards, may impact cable management), Expansion Slots: 7, 5.25" Drive Bays: N/A, 3.5" Drive Bays: 2, 2.5" Drive Bays: 2 (Max.6), I/O Panel - USB Ports: 1x USB 3.2 Gen1 Type A, 1x USB 3.2 Gen1 Type C​, I/O Panel - Audio In / Out: 3.5 mm Combo x 1, Fan Support - Front: (Filtered) 140 mm x 3 / 120 mm x 3, Fan Support - Top: (Filtered) 140 mm x 2 / 120 mm x 3, Fan Support - Rear: 1x 120mm, Pre-installed Fans - Front: 3x 120mm ARGB Fans, Pre-installed Fans - Top: N/A, Pre-installed Fans - Rear: N/A, Radiator Support - Front: 120 / 140 / 240 / 280 / 360 / 420 mm (Limit: 457*140*27 mm), Radiator Support - Top: 120 / 140 / 240 / 280 / 360mm, Radiator Support - Rear: 120mm, Clearance - CPU Cooler: 170mm, Clearance - PSU: 170 / 210mm (w/o HDD Cage), Clearance - Graphics Card (installed 3.5"HDD BRK): 360 / 410 mm (w/o front radiator), Cable Routing - Behind Motherboard Tray: 33-35 mm, Dust Filters: Top, Front, Bottom, Power Supply Support: ATX, Warranty: 2 years, Series: Elite Series, Size: Mid Tower
