DeepCool CH160 MESH özellikleri ve fiyatları

DeepCool CH160 MESH teknik özellikleri

Model kodu

CH160 MESH

part Number

R-CH160-BKNMI0-G-1

case Form Factor

mini-ITX

motherboard Support

Mini-ITX

Boyutlar

336×200×283.5mm(L×W×H)

panel Materials

ABS+PVC+SPCC

front Io

USB3.0×2、Audio×1、Gen2 Type-C×1

fan Mounts

Front: 1×120 mm（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three）; Top: 2×120mm; Side: 2×120mm; Rear: 1×120mm

radiator Support

Side：240mm

psu Form Factor

ATX PS2（maximum length: 140mm）/ SFX / SFX-L

clearance Conditions

CPU Cooler Height Limit: 172mm; GPU Size Limit: Length: SFX/SFX-L: 305mm / ATX: 230mm; Height: 138mm; Width: 65mm (3 Slots)

drive Bays

3.5" Drive Bays: 1（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three）; 2.5" Drive Bays: 1（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three）

Ağırlık

3100 g

device Depth

336

En

200 mm

Boy

283.5 mm

expansion Slots

3

cpu Cooler Max Height Mm

172

Üreticinin ayrıntılı teknik bilgileri

Product Dimensions: 336×200×283.5mm(L×W×H), Net Weight: 3.1Kg, Materials: ABS+PVC+SPCC, Motherboard Support: Mini-ITX, Front I/O Ports: USB3.0×2、Audio×1、Gen2 Type-C×1, 3.5" Drive Bays: 1（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three）, 2.5" Drive Bays: 1（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three）, Expansion Slots: 3 Slots, Pre-Installed Fans: None, Fan Support: Front: 1×120 mm（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three）; Top: 2×120mm; Side: 2×120mm; Rear: 1×120mm, Radiator Support: Side：240mm, CPU Cooler Height Limit: 172mm, GPU Size Limit: Length: SFX/SFX-L: 305mm / ATX: 230mm; Height: 138mm; Width: 65mm (3 Slots), Power Supply Type: ATX PS2（maximum length: 140mm）/ SFX / SFX-L, EAN: 6933412774013, P/N: R-CH160-BKNMI0-G-1
